Product Description:

The DDS02.2-W015-BA01-01-FW is a digital AC servo drive controller built by Bosch Rexroth Indramat for the DDS Drive Controllers series. It regulates current and voltage to matched servo motors, providing position or velocity control in automated assembly cells, material-handling stations, and packaging equipment where coordinated axis motion is required. Mounted on a common backplane with other DDS units, it forms part of a modular multi-axis rack. This arrangement lets several drives be installed side by side while keeping the cabinet layout consistent across larger motion systems.

Electrical delivery is capped at a continuous 15 A, which is the maximum phase current the drive supplies without derating. Command signals arrive through an analog interface, so the unit can accept ±10 V references for speed or torque control. Feedback is accepted through digital servo feedback and resolver feedback, enabling encoder-based or resolver-based loop closure. Heat is removed by air from inside the control cabinet; this arrangement requires cabinet ventilation but avoids onboard fans. The electronics sit behind an IP20 front that prevents finger contact and is suited to clean enclosures. This front protection is intended for cabinet installation rather than direct exposure on open machine frames.

The specified ambient range of 0 to 45 °C supports normal operation, while storage is permitted from -30 to 85 °C when the unit is not in use. Altitude capability reaches 1000 m before current reduction is necessary, which covers most standard industrial locations. The unit is part of Line 02, uses Function ID 01 with Function ID Version 01, and is built in Hardware Version 2. These identifiers distinguish the drive within the DDS platform. The shared DDS backplane also allows mixed axes to draw energy from a single supply, which helps reduce cabinet wiring complexity.
