Product Description:

The DDS02.2-A200-BE76-01-FW is an AC servo drive controller produced by Bosch Rexroth Indramat for the DDS Drive Controllers series. Installed inside multi-axis cabinets, the unit converts command data from a central motion processor into controlled three-phase output that drives attached servo motors. By supervising current, velocity, and position loops in real time, it supports accurate motion in packaging lines, handling robots, printing equipment, and other machines that must repeat movement within tight mechanical tolerances. Its modular design also suits systems where several axes are grouped in the same control cabinet.

Its communication layer relies on the SERCOS interface, so real-time setpoints and operating data move through fiber-optic rings with deterministic timing. The power section is rated for 200 A, enabling the controller to operate large-frame motors during acceleration without current foldback. Feedback can be handled through digital servo feedback for high-resolution encoders or resolver feedback for motors that use rugged analog transducers. Thermal management uses external air cooling, meaning cooling air is drawn from outside the cabinet and passed across the heatsink so internal components remain within their allowed operating temperature range.

The unit carries Function ID 01, which marks the configured function set for this drive type. It is part of Line 02, which uses the second-generation DDS mechanical footprint and connector arrangement. The controller is built as Version 2, indicating a later production revision within this product line. In operation, the unit functions as a Digital AC servo drive controller, processing current, speed, and position control fast enough to coordinate multiple axes from the same control system. This layout allows the drive to fit into cabinet-based automation systems that require direct integration with compatible Rexroth motor and control hardware.
