Product Description:

The DDS02.1-W200-DS24-03-FW is manufactured by Bosch Rexroth Indramat and belongs to the DDS Drive Controllers series. It functions as a digital AC servo drive controller. It conditions three-phase power and exchanges position, velocity, and diagnostic data with motion controllers in industrial automation cells. In automated equipment, it serves as the power stage between the control system and the motor. This supports coordinated axis motion during continuous machine operation.

Communication with higher-level control systems is carried out through the SERCOS interface, enabling deterministic fiber-optic networking between multiple axes. The drive can supply up to 200 A of continuous output current to compatible Indramat servo motors, so cabinet wiring and upstream protection devices must be sized for that load. Its housing is classified as IP20, which protects internal electronics against finger contact but requires installation in a closed electrical cabinet. Cooling air is drawn across the heat sink from within the enclosure, and the specified method is air from inside the control cabinet. This arrangement keeps the cooling path inside the enclosure rather than pulling air directly from outside the cabinet. Closed-loop regulation relies on digital servo feedback, meaning the associated motor encoder transmits position data to the drive for speed and torque control. The feedback channel allows the drive to monitor rotor movement continuously and correct command deviations in real time.

The permissible ambient range is 0 to 45 °C, so any cabinet conditioning must keep the electronics within these limits during operation. When powered down, components tolerate a storage window of -30 to 85 °C, which supports shipment or storage in non-climate-controlled spaces. Installation altitude is limited to 1000 m above sea level because reduced air density lowers heat removal. These operating limits matter when the controller is mounted with other heat-producing modules in the same enclosure. The drive is part of Line 02 in the DDS platform.
