DDS02.1-W200-DS01-02-FW/S003
MPN: R911271266
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
-
In-Stock, Ships 3-5 Days
The Bosch Rexroth Indramat DDS02.1-W200-DS01-02-FW/S003 is a modular drive controller from the DDS Drive Controllers series, designed for panel mounting with internal air cooling. It supports a rated current of 200A, an IP20 enclosure, and SERCOS communication interface. It weighs approximately 6–8 kg.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
Bosch Rexroth Indramat company designed and manufactured the DDS02.1-W200-DS01-02-FW/S003 Drive Controller. This controller uses internal cabinet air cooling marked as type W and is very useful in industrial automation systems. It supports a current supply of 200 amperes. Its continuous current is approximately 80 amperes. The device operates at a DC bus voltage of 300 V ±15%.
The DDS02.1-W200-DS01-02-FW/S003 drive controller uses Digital Servo Feedback for motor feedback handling. The supported motor feedback interface is located at port X4. The serial interface RS232 is accessible through the connector X2. The device weighs between 8.5 and 9.0 kilograms. A special version, S003, includes customized firmware settings. Its firmware module must be ordered as DSM02.1-FW. The operational temperature range is +5 °C to +45 °C, while its storage temperature ranges from –25 °C to +85 °C. It also withstands 1 g vibration between 57 and 150 Hz. The terminal incorporates a SERCOS interface that operates through a fiber-optic link. The interface is assigned a Function ID of 01 and utilizes version 02. This unit carries a protection class rating of IP10. A signal voltage input supports a range of 5 to 30 volts. The voltage level remains within a protective low-voltage range. The device is built for reliable cabinet installations
The DDS02.1-W200-DS01-02-FW/S003 drive controller supports digital communication through the SERCOS standard. This controller ensures real-time closed-loop control feedback. The design is compact and suitable for vertical mounting. All interface ports are assigned for simplified wiring. Firmware installation must match the specific function version settings. A correct port usage is critical for full controller functionality. Its grounding through a PE connection is strictly required. The discharge current exceeds 3.5 mA, needing proper grounding. It is designed specifically for servo motor control systems.
Frequently Asked Questions about DDS02.1-W200-DS01-02-FW/S003:
Q: What role does port X4 play in DDS02.1-W200-DS01-02-FW/S003 functionality?
A: Port X4 is the motor feedback interface that connects to the digital servo encoder. It ensures accurate position and speed feedback in the system.
Q: Why is vertical mounting specified for DDS02.1-W200-DS01-02-FW/S003?
A: Vertical mounting optimizes internal airflow for cooling and complies with installation safety standards. DDS02.1-W200-DS01-02-FW/S003 is engineered to operate optimally in this orientation.
Q: How does the signal voltage range improve compatibility in DDS02.1-W200-DS01-02-FW/S003?
A: The input range of 5 to 30 volts ensures compatibility with varied industrial signal systems. DDS02.1-W200-DS01-02-FW/S003 can interface with diverse control setups.
Q: Why is grounding essential in the DDS02.1-W200-DS01-02-FW/S003 system?
A: The device exceeds 3.5 mA discharge current, requiring proper PE grounding. This ensures user safety and protects internal components from electrical surges.
Q: Why is the RS232 interface (X2) important in the DDS02.1-W200-DS01-02-FW/S003?
A: RS232 at connector X2 allows for direct serial communication with diagnostic tools. This aids in configuring, troubleshooting, and maintaining the system effectively.
