Product Description:

The DDS02.1-W200-DL40-01-FW is a digital AC servo drive controller produced by Bosch Rexroth Indramat and supplied within the DDS Drive Controllers series. Designed to regulate a single motor axis in automated machinery, the unit converts command signals from a higher-level control into precisely metered three-phase output for synchronous and induction servo motors. It serves as the power stage for closed-loop positioning tasks, translating control commands into responsive motor current. Because the controller regulates current in real time, it can maintain smooth motion during indexing, feed moves, and speed-controlled process steps.

Within the controller, the communication channel is optimized for single-axis position control, allowing direct velocity and position commands without intermediate multiplexing. The unit provides a continuous output of 200 A under rated conditions, and protective electronics monitor current demand to help prevent overcurrent shutdowns. All circuitry is enclosed by an IP20 housing, so the controller must be installed inside a switch cabinet to limit accidental contact and exposure to debris. Thermal management relies on air from inside the control cabinet, which means cabinet airflow must remove the heat produced during operation. Rotor angle information is accepted through digital servo feedback, allowing the control loop to correct position and speed deviations quickly. Reliable operation is permitted in ambient temperatures from 0 to 45 °C during continuous duty.

When powered down, the unit can be stored at temperatures from –30 to 85 °C without harming passive components or insulation materials. These storage limits apply while the controller is not energized or installed in service. Installation altitude is limited to 1000 m above sea level because thinner air reduces cooling effectiveness for internally ventilated equipment. The function package identified by version 01 works with Line 02 hardware and Version 1 drive logic, keeping the controller aligned with compatible DDS parameter sets.
