Product Description:

The DDS02.1-W200-DL04-01-FW is a servo drive controller produced by Bosch Rexroth Indramat for the DDS Drive Controllers series. It is used in multi-axis automation racks to energize and regulate synchronous and induction motors so industrial machines can follow programmed motion profiles with repeatable accuracy. By closing the current and velocity loops locally, the controller offloads high-speed calculations from the main PLC. This shorter control path helps the axis respond quickly to load changes during acceleration, deceleration, and steady-speed operation. It is suited for production lines, pick-and-place systems, and packaging equipment where coordinated motion must remain consistent through repeated cycles.

This model delivers a continuous output of 200 A, so the connected motor can reach rated torque without the drive saturating. Heat is removed through internal air cooling, meaning cabinet air moves across the heat sink rather than relying on external ducting. The housing is rated IP20, so it is intended for installation in clean enclosures while still allowing straightforward wiring access. Operating temperature ranges from 0 to 45 °C, and temperatures outside that band can require derating or shutdown to protect the power section. The permitted installation altitude reaches 1000 m above sea level before additional cooling or spacing is needed. These limits make cabinet ventilation and placement important when the controller is used at high load for long periods.

Command data arrive through a single-axis position control interface, and motor status returns through digital servo feedback, which supports accurate motion control and fault monitoring during axis movement. This combination lets the drive process command and feedback signals directly at the axis instead of sending every fast correction back to the main control. Application-specific software is ordered separately so the drive can be matched to the required control method, such as SERCOS or analog speed setpoints. The unit is part of Line 02, and it carries Function ID Version 01 and hardware Version 1. It can be stored from -30 to +85 °C, which allows spare units to remain in storage areas that are not climate controlled.
