DDS02.1-W200-DL02-00 Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911261587
The Bosch Rexroth Indramat DDS02.1-W200-DL02-00 is a digital AC servo drive controller and part of the DDS Drive Controllers series. It offers single-axis position control, digital servo feedback, and features an internal air cooling method. The controller is rated for 200 Amps, supports operation at elevations up to 1000 meters, and has an IP20 protection category.
Internal Product Review
The DDS02.1-W200-DL02-00 is a digital AC servo drive controller designed for precise single-axis position control. Internal cabinet air cooling and digital servo feedback support stable performance in well-integrated motion systems. IP20 protection and a 200A rated current make the controller a strong choice for demanding servo applications.
Have a part to sell?
Wake Industrial Warranty
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The DDS02.1-W200-DL02-00 is produced by Bosch Rexroth Indramat as part of the DDS Drive Controllers series. Classified as a digital AC servo drive controller, it interfaces with higher-level PLCs to govern motor torque, speed, and position in automated assembly stations, material-handling gantries, and packaging equipment. Within the series, this model belongs to line 02 and combines power electronics with motion logic so that a single cabinet module can close the drive's internal control loops without external motion cards. It is suited to applications that need repeatable positioning and stable speed regulation on a dedicated axis. In automated cells, it can coordinate acceleration, velocity changes, and settling behavior for a single motor-driven axis.
To execute precise motion programs, the drive provides single-axis position control, allowing the connected motor to follow absolute or incremental position commands with tight accuracy. For the required power headroom, its bus and inverter stages are rated for 200 A of continuous output current, which supports demanding acceleration and sustained torque on larger servo axes. Encoder data enters through digital servo feedback, enabling real-time comparison between commanded and actual rotor angle so correction occurs during motion. Thermal energy is extracted by internal air cooling, meaning air is drawn from inside the control cabinet and expelled through the heat-sink fins. The IP20 housing protects live parts from direct finger contact, so the unit must be installed inside a suitable enclosure for dust and moisture protection.
The controller can be mounted in machinery rooms situated up to 1000 m above sea level without derating. It is intended to operate in ambient temperatures from 0 to 45 °C, which suits typical industrial control cabinets with managed airflow. When the unit is unpowered, storage is allowed from -30 to 85 °C for transport or warehouse conditions. The controller is Version 1. These limits should be considered when the drive is installed near other heat-producing modules or in cabinets with restricted airflow.
