Product Description:

The DDS02.1-W200-DL01-01-FW drive controller is produced by Bosch Rexroth Indramat. It is a digital AC servo drive controller that operates between the power supply and a servo motor to regulate torque, speed, and position on a dedicated axis. Because the power stage and control functions are housed in one unit, it can manage motor response directly on a single machine axis without separate signal converters. This control role supports accurate motion in automated equipment such as pick-and-place stations, index tables, and material-handling systems. Closed-loop axis control helps the machine follow commanded movement profiles with steady response during repeated operating cycles.

Inside the cabinet, the controller is cooled by air drawn from inside the control cabinet, so it does not require ducted external air. Its output stage is rated for 200 A, which sets the current capacity available to the connected motor. That level suits axes that need high continuous motor current during acceleration and sustained load. Command data are handled through the single-axis position control interface, allowing the unit to carry out axis motion without an added motion card. Encoder signals return through digital servo feedback, which supports closed-loop current and speed control during operation.

The controller belongs to the DDS Drive Controllers series and is assigned Line 02, which places it within the mechanical format used by related modules. Modules in this line share cabinet mounting dimensions and connector placement with companion units. It carries Function ID 01, and the associated function-ID version is 01 for this configuration. The unit is also listed as Version 1, indicating the product revision used for this controller. In a modular drive system, the controller can be combined with an upstream supply module to form a complete axis package for servo applications.
