Product Description:

The DDS02.1-W200-DA06-01-FW is a drive controller produced by Bosch Rexroth Indramat as part of the DDS Drive Controllers series. It converts the DC link from a shared power supply into controlled three-phase output for synchronous servo motors, allowing precise speed and torque regulation in machining centers, packaging lines, and automated assembly cells. Within an Indramat multi-axis rack, the unit occupies the slot assigned to one motor axis and supplies both power and closed-loop regulation. Because it operates from the common DC link, several axes in the same cabinet can use one central power section.

Classified as a Digital AC Servo Drive Controller, the device integrates gate-drive logic, current regulators, and diagnostic circuits. Its power stage can deliver up to 200 A of continuous phase current, which supports high-torque motors during sustained operation. Motion references reach the controller through an analog interface, and it accepts ±10 V velocity or torque commands directly from legacy PLC hardware. Heat is removed by internal air cooling, so cabinet ventilation fans move air across the heat sink and no rear chimney or liquid loop is required. Motor position returns through digital servo feedback, providing high-resolution data for vector control and fast fault recognition.

The controller carries Function ID 01, belongs to Line 02, and is assembled in hardware Version 1. These identifiers place the module within the DDS platform and set the control arrangement used by this unit. The required control software is supplied as a separate subitem, and the selected package can enable functions such as spindle orientation, winding tension control, or coordinated cam profiles. This arrangement allows the controller to be matched to the intended axis behavior without changing the base hardware.
