Product Description:

The DDS02.1-W150-DS15-00 is a digital AC servo drive controller manufactured by Bosch Rexroth Indramat and used in the DDS Drive Controllers series. Mounted near the machine axis, it converts DC bus energy into controlled three-phase output so that robots, packaging stations, and transfer lines can regulate torque, speed, and position during automated cycles. When paired with a compatible servo motor, the unit supports closed-loop motion tasks that depend on fast current control and stable speed regulation. This makes it suitable for equipment that must repeat the same move profile across frequent start, stop, and indexing sequences.

Command exchange occurs over the fiber-optic SERCOS interface, while rotor position is returned through digital servo feedback for closed-loop control. This combination gives the controller a direct command path from the higher-level motion system and a continuous position signal from the motor. The power section can deliver a continuous phase current of 150 A, which supports demanding acceleration and steady motor loading on larger axes. Thermal dissipation relies on air from inside the control cabinet, so cabinet airflow must stay clear across the heat sink and surrounding components. The housing has an IP20 rating, which limits ingress to objects larger than 12.5 mm and calls for additional guarding in exposed locations. Full output is supported in ambient temperatures from 0 to 45 °C.

Installation altitude may reach 1000 m without derating, which suits many standard factory elevations. During shipment or storage, the electronics tolerate temperatures from -30 to 85 °C, helping the unit endure seasonal transport and unconditioned storage areas. The unit is part of Line 02, which identifies its power-stage layout and connector arrangement within the DDS platform. It also carries Version 1 for parameter handling and diagnostics. These identifiers help keep documentation and parameter records aligned with the installed unit.
