DDS02.1-W100-DS58-01-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911279685
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
6 Minutes
35 Seconds
The Bosch Rexroth Indramat DDS02.1-W100-DS58-01-FW is a digital AC servo drive controller from the DDS Drive Controllers series. It features a SERCOS communication interface and supports digital servo feedback for motor control. The controller has a rated current of 100 Amps and uses internal air cooling from within the control cabinet.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The DDS02.1-W100-DS58-01-FW digital AC servo drive controller is manufactured by Bosch Rexroth Indramat and belongs to the DDS Drive Controllers series. It governs current, velocity, and position loops of compatible servo motors, allowing machine control systems to run precise motion profiles on production equipment. By combining regulated power stages, fieldbus communication, and device monitoring in one compact module, the drive supports modular multi-axis cabinet layouts and reduces the amount of separate wiring needed for each axis. This arrangement supports coordinated motion tasks in automated machinery where stable speed regulation and accurate positioning are required. Because the power stage and communication functions are housed together, the controller fits well in centralized control cabinets that manage several axes at the same time.
The controller can deliver a continuous output of 100 A, which is the maximum steady motor current the internal power stage can provide without thermal derating. Command data reach the drive through the SERCOS interface, providing deterministic communication between the CNC or PLC and the axis controller during operation. Rotor position returns through digital servo feedback, allowing the drive to correct speed and position in real time as load conditions change. Cooling is provided by air from inside the control cabinet, so the enclosure must move enough airflow across the heat sink, and the unit is part of Line 02 within the DDS range.
The unit carries Function ID 01 and is built as Version 1. These identifiers mark the assigned function set and product revision used for this controller, keeping the drive description clear within the product line. In use, the drive serves as a digital AC servo drive controller for applications that need accurate axis response and consistent control behavior during repeated machine cycles. It is intended for closed-loop servo operation in equipment that relies on coordinated current, speed, and position control from a central CNC or PLC.
Frequently Asked Questions about DDS02.1-W100-DS58-01-FW:
Q: What communication interface is available on the DDS02.1-W100-DS58-01-FW drive controller?
A: The DDS02.1-W100-DS58-01-FW supports a SERCOS interface for communication.
Q: How is the DDS02.1-W100-DS58-01-FW drive controller cooled?
A: Cooling is achieved by moving air from inside the control cabinet using an internal method.
Q: What is the rated current for the DDS02.1-W100-DS58-01-FW controller?
A: This model features a rated current of 100A for demanding servo applications.
Q: What type of motor feedback does the DDS02.1-W100-DS58-01-FW utilize?
A: Motor feedback for this drive uses a digital servo feedback system.
Q: What version is the DDS02.1-W100-DS58-01-FW drive controller?
A: The version of this unit is Version 1, as indicated in its specifications.
