The Bosch Rexroth Indramat DDS02.1-W100-DS51-01-FW is a digital AC servo drive controller from the DDS Drive Controllers series. It offers a rated current of 100 Amps and features a SERCOS communication interface. This controller uses air cooling from inside the control cabinet and provides digital servo feedback, with a protection category of IP20.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The DDS02.1-W100-DS51-01-FW drive controller is produced by Bosch Rexroth Indramat within the DDS Drive Controllers series. This digital AC servo drive controller acts as an axis module that regulates three-phase output for servo motors in automated machinery, converting motion commands into precisely timed current pulses. It installs alongside compatible supply units in a shared backplane to create compact multi-axis racks for packaging lines, printing presses, and material-handling systems. That arrangement allows one control platform to coordinate several motion axes in a single cabinet without requiring separate standalone drive housings for each motor.
Communication with the higher-level control is handled through a SERCOS interface, enabling deterministic cycle times and standardized telegram structures for closed-loop motion control and diagnostics. The power section delivers a continuous phase current of 100 A, so the drive can energize medium-power motors without current foldback under rated load. Thermal management relies on air from inside the control cabinet, so the unit draws ambient panel air across its heat sink and requires adequate enclosure ventilation. With a protection class of IP20, live parts are protected against accidental finger contact, but the controller must be mounted inside an electrical cabinet. Feedback is processed through digital servo feedback, providing position and velocity data for accurate axis regulation. Reliable operation is permitted between 0 – 45 °C, where the controller maintains its electrical performance.
Additional parameters cover storage and installation limits for the controller. The electronics can be stored or transported between -30 – 85 °C without harming standard electrical components when the unit is not energized. Mounting is permissible at heights up to 1000 m above sea level before derating is required. The function ID version is 01, and the controller is part of Line 02 with Version 1 hardware. These identifiers distinguish the product revision used for this model.
Frequently Asked Questions about DDS02.1-W100-DS51-01-FW:
Q: What communication interface is available on the DDS02.1-W100-DS51-01-FW drive controller?
A: The DDS02.1-W100-DS51-01-FW supports SERCOS interface communication for integration into automation systems.
Q: What is the rated current of the DDS02.1-W100-DS51-01-FW controller?
A: This model provides a rated current of 100 A, suitable for demanding servo applications.
Q: How is the DDS02.1-W100-DS51-01-FW cooled during operation?
A: Cooling for the DDS02.1-W100-DS51-01-FW is handled via internal air circulation within the control cabinet.
Q: What is the operating temperature range for this drive controller?
A: The DDS02.1-W100-DS51-01-FW operates within an ambient temperature range of 0 to 45°C.
Q: What kind of motor feedback system does the DDS02.1-W100-DS51-01-FW use?
A: This controller provides digital servo feedback for motor feedback applications.
