Product Description:

The DDS02.1-W100-DS46-00-FW is a digital AC servo drive controller from Bosch Rexroth Indramat in the DDS Drive Controllers series. It conditions three-phase power and manages current and speed loops for synchronous or asynchronous motors under CNC or PLC command. The unit is part of Line 02 and Version 1, so it fits standard Indramat drive racks used in multi-axis packaging, printing, and material handling systems. It also integrates with DIAX04 supply units and operates on a common DC bus, which allows neighboring axes to share available bus energy inside the same drive assembly. This arrangement keeps the power stage separate from the motor while allowing the controller to regulate torque and speed precisely across coordinated axes.

Its continuous output rating of 100 A lets connected motors produce high torque without overloading the supply under normal operating conditions. Motion commands, status words, and diagnostics are transmitted over the SERCOS interface, providing reliable fiber-optic communication between the drive and the control system. Thermal control relies on internal air cooling, so cabinet airflow must move through the enclosure to carry heat away from the power section. Position signals arrive through digital servo feedback, allowing accurate commutation and fast response to changing loads. That feedback path lets the controller evaluate rotor position and velocity directly inside the drive rather than through a separate external device. The housing has an IP20 rating, which helps prevent accidental finger contact with live parts but still requires installation inside an electrical cabinet.

Installation limits should be observed to maintain full performance. The permissible operating temperature range is 0 to 45 °C, and the air inside the cabinet must remain within that range for full current output. Performance is maintained up to 1000 m above sea level, while higher elevations reduce cooling effectiveness and may require output derating. During storage or transport, the controller can remain within a temperature range of -30 to +85 °C without damage to internal electrical components if it is not in operation. These limits should be considered along with cabinet ventilation and site elevation during system layout.
