DDS02.1-W100-DS24-02 Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911266282
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
5 Minutes
10 Seconds
The Bosch Rexroth Indramat DDS02.1-W100-DS24-02 is a digital AC servo drive controller in the DDS Drive Controllers series. It has a rated current of 100 Amps and an operating temperature range of 0 to 45 degrees Celsius. The controller offers a SERCOS communication interface, digital servo feedback for motor control, and is rated IP20 for protection.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The DDS02.1-W100-DS24-02 is a digital AC servo drive controller manufactured by Bosch Rexroth Indramat within the DDS Drive Controllers series. Acting as the intermediary between a motion controller and a synchronous motor, the unit modulates three-phase power so that closed-loop positioning and velocity commands are executed accurately in automated machinery and assembly lines. It is suited for multi-axis equipment where repeatable motion and stable speed control are required. It is commonly used in packaging machines, transfer systems, and other automated stations that depend on coordinated axis movement.
Communication with higher-level control hardware is established through the SERCOS interface, allowing deterministic exchange of setpoints and diagnostic data over fiber-optic cabling. Thermal regulation relies on air cooling inside the control cabinet, with enclosure air passing across internal heat sinks instead of using external blowers. The power section is rated for a continuous output of 100 A, enabling the controller to drive medium-to-large servo motors without current derating in normal duty cycles. An enclosure classification of IP20 indicates finger-safe openings and protection against solid objects larger than 12.5 mm, making the device suitable for installation in closed electrical panels. Reliable operation is specified for ambient temperatures between 0 to 45 °C, so the drive can be mounted alongside other control electronics when cabinet airflow is maintained.
Continuous functionality is maintained up to 1000 m altitude, where reduced air density still supports the internal cooling path. When the machine is powered down, components tolerate storage conditions from -30 to +85 °C without damage to capacitors or solder joints. Motor position data is exchanged through digital servo feedback, enabling the controller to close the velocity loop with minimal latency. This feedback method supports accurate commutation and stable position tracking during dynamic moves. The product is part of Line 02.
Frequently Asked Questions about DDS02.1-W100-DS24-02:
Q: What type of communication interface does the DDS02.1-W100-DS24-02 use?
A: The DDS02.1-W100-DS24-02 drive controller features a SERCOS communication interface.
Q: How is the DDS02.1-W100-DS24-02 servo drive cooled?
A: This model uses internal air cooling, moving air from inside the control cabinet.
Q: What is the rated output current for the DDS02.1-W100-DS24-02 drive controller?
A: The DDS02.1-W100-DS24-02 is rated for a continuous current of 100A.
Q: What type of motor feedback does the DDS02.1-W100-DS24-02 support?
A: It is equipped with digital servo feedback for precise motor position control.
Q: What is the protection category classification of the DDS02.1-W100-DS24-02?
A: The protection category for this drive controller is IP20.
