Product Description:

The DDS02.1-W100-DS01-01 is a servo drive controller produced by Bosch Rexroth Indramat for installations that use the DDS Drive Controllers series. Its purpose in factory automation is to regulate power for Indramat synchronous and asynchronous servomotors, translating motion commands from a host controller into accurately timed three-phase currents so machinery holds position, tracks velocity profiles, and executes coordinated moves. By sharing a common DC bus with adjacent converters, it helps shrink cabinet footprints and allows kinetic energy exchange between axes during acceleration and braking. This arrangement supports coordinated motion in packaging lines, transfer systems, and machine tools where several axes must respond to one control platform.

Delivering a continuous output of 100 A, the drive can energize medium-inertia axes such as gantry carriages or press feeders without exceeding its thermal limit. Command and diagnostic data are exchanged over the SERCOS interface; the optical ring supports deterministic timing and allows up to 64 drives to share one master. Heat is removed by internal air cooling, so cabinet airflow must keep inlet temperatures within the allowable range. Rotor position information returns through digital servo feedback, enabling high-gain loops without analog drift. The closed feedback path allows the controller to correct speed and position deviations caused by changing loads. The unit carries Function ID 01.

As a Digital AC Servo Drive Controller, the unit conforms to the mechanical and electrical layout used for Line 02, so its power terminals, signal connectors, and mounting rails match other second-line modules and align with standard DDS cabinet assembly. The module format supports slide-in installation on the system rails used in multi-axis cabinets. The unit uses Function ID Version 01 for this control configuration. The product is hardware version 1.
