Product Description:

The DDS02.1-W100-DA03-00 is a digital AC servo drive controller produced by Bosch Rexroth Indramat for the DDS Drive Controllers series. Installed in centralized control panels, it converts velocity and position setpoints into regulated three-phase power so that synchronized servo axes in automated assembly cells, printing machinery, and gantry systems can follow commanded profiles with repeatable accuracy. Its cabinet-mounted design supports closed-loop motion tasks where stable torque delivery and consistent axis response are required throughout repeated machine cycles.

The controller exchanges command signals through an analog interface, which is suitable for legacy PLCs that output ±10 V references. Continuous output capability reaches 100 A, providing enough current for rapid acceleration of medium-to-large motors without external booster modules. Heat generated by the IGBT stage is removed by internal cabinet air cooling, so overall enclosure airflow must be sized to keep the power section within its allowable temperature range. All live parts sit behind terminals that meet the IP20 protection category, allowing finger-safe access while still requiring installation inside an enclosure. Position and speed feedback arrive through digital servo feedback, allowing the drive to perform closed-loop regulation and respond quickly to load changes during operation.

The unit operates in ambient temperatures from 0 to 45 °C, and hotter conditions require additional cooling or output derating. During storage, it withstands temperatures from -30 to +85 °C when moisture is controlled so condensation does not collect on internal components. Installation is limited to 1000 m above sea level, where air density remains sufficient for the intended thermal path. The controller is identified as Version 1.
