DDS02.1-W025-RA02-00 Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911257038
The Bosch Rexroth Indramat DDS02.1-W025-RA02-00 is a Digital AC Servo Drive Controller from the DDS Drive Controllers series. It features an analog communication interface and resolver feedback. The controller operates at a rated current of 25 Amps and uses internal air cooling from inside the control cabinet. It is rated for IP20 protection and can be installed at elevations up to 1000 meters.
Internal Product Review
The DDS02.1-W025-RA02-00 is a digital AC servo drive controller rated for 25 A, well suited for precise motion applications. Resolver feedback and internal cabinet air cooling support stable control behavior and practical panel integration. IP20 protection and a 0 to 45°C operating range make the unit a dependable choice for industrial drive systems.
Have a part to sell?
Wake Industrial Warranty
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The DDS02.1-W025-RA02-00 is a drive controller manufactured by Bosch Rexroth Indramat and assigned to the DDS Drive Controllers series. It commands three-phase servo motors in industrial automation cells by modulating voltage and current according to reference signals from a PLC or motion card. Acting between motor feedback and higher-level sequencing, the unit supplies regulated power, monitors axis conditions, and exchanges status data during packaging, material-handling, and machining tasks. It is suited to axis modules that rely on dedicated drive hardware rather than separate external amplifiers, which helps keep motion control functions concentrated in one cabinet location.
This controller delivers a continuous output of 25 A, so it can supply that phase current during normal duty cycles without derating. Command signals enter through an analog interface, which allows velocity or torque setpoints to be sent as voltage or current levels instead of network telegrams. Heat is removed by internal air cooling, so cabinet air must move across the heat sink to keep the power section within its intended operating range. The IP20 enclosure is intended for protected control cabinets, where contact with conductive dust or liquids is avoided. Position and speed are closed through resolver feedback, which gives the drive a stable motor angle signal for commutation and closed-loop regulation.
The drive belongs to Line 02 and is supplied as Version 1, placing it within an established DDS product generation. It can be mounted up to 1000 m above sea level without output reduction, which suits most standard factory installations. Reliable operation is specified at ambient temperatures from 0 to 45 °C, while storage is permitted between -30 and 85 °C when the unit is not in use. The stated storage range helps protect electronic components during warehousing and shipment before installation.
