Product Description:

The DDS02.1-W025-DL22-00 is a digital AC servo drive controller manufactured by Bosch Rexroth Indramat for the DDS Drive Controllers series. It provides closed-loop regulation for induction and synchronous servo motors used in material handling, packaging, and machining centers. Within an automation cell, the unit converts command data from the master control system into precise current and voltage patterns that match motor demand, supporting repeatable axis motion and coordinated positioning. Because the control loop is managed inside the drive, the motor can respond quickly to changing load conditions while maintaining stable speed and accurate positioning during start, stop, and indexing cycles.

This controller executes motion through an interface dedicated to single-axis position control, so one drive directly governs one mechanical axis. Thermal management relies on internal air cooling from inside the control cabinet, meaning cabinet airflow must be maintained instead of supplied by external fan trays. The unit belongs to line 02, the second design iteration, and supplies up to 25 A of continuous output current to the motor windings. Protection is limited to IP20, so the cabinet must shield the electronics from dust and liquid ingress. Operation is permitted in ambient temperatures from 0–45 °C; above this range, derating or additional cooling is required to prevent thermal shutdown.

Altitude is restricted to 1000 m above sea level to maintain normal insulation performance. Position feedback is handled through digital servo feedback, which sends incremental position data and diagnostic information over a differential channel to support stable velocity control. When inactive, the unit can be stored in temperatures from -30 to +85 °C without condensation, which accommodates transport and warehouse storage outside normal operating conditions. The drive is Version 1. This operating range supports installation in standard industrial cabinets and storage in unheated indoor areas when the equipment is not in service.
