Product Description:

The DDS02.1-W015-DL20-01-FW is a digital AC servo drive controller produced by Bosch Rexroth Indramat and assigned to the DDS Drive Controllers series. Designed as a modular rack component, it converts shared DC bus power into three-phase output for a single motor and supervises protective functions. The unit is installed in motion axes where precise speed and position coordination are critical, such as feeders, gantry slides, and print cylinders. By executing vector control algorithms in real time, it links higher-level PLC commands to reliable electric motion in factory automation cells. This arrangement lets the controller handle current regulation, protective monitoring, and motor coordination within a compact cabinet layout.

Electrically, the drive delivers a continuous output of 15 A to the motor phases. This current rating supports continuous torque production in a matched servomotor without thermal overload. Command and diagnostic data move through a single-axis position control interface, so the module handles interpolation and closed-loop corrections internally rather than relying on the master PLC. Feedback returns through digital servo feedback, allowing high-resolution position monitoring and automatic parameter matching. To maintain its electronic components, the unit relies on internal air cooling, and cabinet air is drawn across the heat sink. The housing carries an IP20 rating, which provides finger protection but no sealing against moisture, so the drive must be installed in a cabinet. Active service is permitted between 0 and 45 °C in climate-controlled rooms.

Installation is permitted up to 1000 m above sea level without derating. When powered down, components can be stored from -30 to +85 °C, which supports transport and warehouse storage before installation. The controller carries Function ID version 01 and belongs to Line 02. The unit is version 1.
