Product Description:

The DDS02.1-W015-DL04-01-FW is a digital AC servo drive controller produced by Bosch Rexroth Indramat for the DDS Drive Controllers series. Within an automation cell, this module mounts on a rack-style backplane beside a matching supply and converts DC bus power into controlled three-phase output for a single servomotor. Its integrated position loop and direct feedback interface let machine builders implement compact pick-and-place stations, indexers, or packaging axes that depend on tight velocity and position accuracy.

The controller supplies a continuous output of 15 A, matching the current needs of medium-power synchronous and asynchronous motors in the Rexroth portfolio. Thermal regulation is handled by internal cabinet air cooling, so enclosure airflow must remain unobstructed. Component sealing is limited to IP20, meaning fingers are protected, but dust ingress must be controlled by the cabinet environment. Rotor data is processed through digital servo feedback, allowing closed-loop current, speed, and position regulation without external converters. All electronic sections are rated for an ambient range of 0 to 45 °C, enabling operation alongside other heat-generating drives when the specified limit is respected.

When powered down, the unit withstands storage temperatures of -30 to 85 °C, supporting long-term warehousing before installation. Reliable service is specified up to 1000 m elevation, covering typical plant altitudes without derating. Motion commands follow a single-axis position control profile executed by the onboard processor for coordinated servo operation. The drive belongs to Line 02 of the DDS family, so its connectors and mechanical footprint align with other second-generation modules. Application software is loaded separately to match the connected motor and required control functions.
