DDS02.1-A200-DL22-01-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911271786
The Bosch Rexroth Indramat DDS02.1-A200-DL22-01-FW is a digital AC servo drive controller in the DDS Drive Controllers series. It features a rated current of 200 Amps and digital servo feedback for motor communication. The unit uses external air cooling and is rated for operation up to 1000 meters elevation, with IP20 protection.
Internal Product Review
The DDS02.1-A200-DL22-01-FW is a digital AC servo drive controller built for single-axis position control. External cabinet air cooling and digital servo feedback support stable integration in demanding motion systems. A 200 A rated current makes this unit a strong choice for high-performance servo applications.
Have a part to sell?
Wake Industrial Warranty
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The DDS02.1-A200-DL22-01-FW is a digital AC servo drive controller produced by Bosch Rexroth Indramat and belongs to the DDS Drive Controllers series. Intended for industrial automation, the unit regulates current and velocity for matched servo motors, allowing precise closed-loop motion in multi-axis machinery. As a drive controller, it links the power section, motor feedback, and higher-level control, supplying regulated energy so that mechanical axes can follow programmed trajectories with repeatable accuracy. Its control stage works with compatible power and feedback circuits so the drive can manage acceleration, steady running, and deceleration on automated axes without losing loop stability.
During operation, the controller can deliver a continuous output of 200 A, enabling it to support medium-to-high power servo motors without current derating inside its specified limits. Thermal management relies on external air cooling, meaning ambient air is drawn from outside the control cabinet and directed across the heat sink. The electronics are safeguarded by an IP20 housing, which is suitable for installation in closed panels where no falling liquids are present. Rated performance is maintained within an ambient range of 0 to 45 °C, and altitude is limited to 1000 m above sea level to avoid reduced cooling performance and excessive dielectric stress around the power components. These operating limits suit enclosed cabinet installation with stable airflow and adequate clearance around the heat sink.
For axis coordination, the drive accepts command words through a single-axis position control interface while monitoring motor position with digital servo feedback, and this pairing supports rapid loop closure for accurate positional stops. This control arrangement helps the servo loop react quickly to changing load conditions during positioning and speed regulation. The drive belongs to function group 2 and line 02, and it carries function ID 01 with version 1 in the type code. When idle or stored, the electronics tolerate temperatures from -30 to 85 °C without degradation. That storage range supports powered-down transport and warehouse storage before installation.
