Product Description:

The DDS02.1-A100-DS06-01/S002 is a digital AC servo drive controller built by Bosch Rexroth Indramat for the DDS Drive Controllers series. It mounts in a modular control cabinet and governs compatible servo motors by converting command data from a motion processor into regulated three-phase output. In industrial automation, this unit coordinates acceleration, deceleration, and continuous running conditions so connected equipment can follow programmed motion profiles with repeatable accuracy. Its role is to provide the power stage and closed-loop control needed for precise axis movement in automated machinery.

Communication with higher-level controls is handled through the SERCOS interface, which allows deterministic fiber-optic bus cycles and direct parameter access. Heat is removed by external air cooling, with cabinet air drawn across the heat sink while the electronics remain inside the enclosure. The power stage supplies up to 100 A of continuous output, so the controller can support demanding servo axes without current sharing between multiple amplifiers. The enclosure has an IP20 degree of protection, which provides finger-safe shielding but does not seal against liquids. Safe operation is permitted at ambient temperatures from 0 to 45 °C, and the control loops use digital servo feedback for position and speed regulation without analog drift.

The controller maintains full output up to an installation height of 1000 m, which suits most indoor factory locations. When powered down, it can be stored at temperatures from -30 to 85 °C, allowing transport or indoor storage where climate conditions vary. These limits help protect internal components such as capacitors and seals during non-operating periods. The unit uses Function ID version 01, and it is assigned to Line 02 with hardware version 1. This coding identifies the control variant used for the drive.
