Product Description:

The DDS02.1-A100-DL40-01-FW is a drive controller built by Bosch Rexroth Indramat within the DDS Drive Controllers series. Positioned between a higher-level PLC and an AC servomotor, it converts motion commands into regulated phase current so industrial axes follow programmed trajectories accurately. The unit supervises motor position, adjusts torque in real time, and supports synchronized motion in material-handling, pick-and-place, and packaging equipment. By closing the control loop inside the drive, it helps the motor react smoothly to changing loads, acceleration ramps, and stopping points during repeated machine cycles. In daily operation, it processes command changes continuously so the axis can accelerate, run at speed, and decelerate with controlled transitions.

The controller has a rated output of 100 A, which is the continuous current available to the connected motor. Heat is removed by external air from outside the control cabinet, so ambient air passes across the heat sink instead of recirculating warmer cabinet air. Position is verified through digital servo feedback, allowing the control loop to correct speed and position errors quickly. Command data are handled through single-axis position control, so one mechanical axis is addressed directly. The unit is a Digital AC Servo Drive Controller that converts incoming power for motor use and monitors operating conditions such as current, temperature, and feedback status during operation. That combination suits applications that need tight response and stable motion over repeated duty cycles.

The unit carries Function ID 01, belongs to Line 02, and is Version 1. These identifiers keep the controller within a consistent parameter set for this model. The coded values are useful when matching configuration data to the correct product generation. That consistency supports stable interaction with compatible motors and control hardware in automated machinery.
