CSH01.3C-ET-EN2-NNN-CCD-S2-S-NN-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911332574
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
4 Minutes
33 Seconds
The Bosch Rexroth Indramat CSH01.3C-ET-EN2-NNN-CCD-S2-S-NN-FW is part of the CSH Advanced Controllers series and operates on a 24 VDC supply voltage. It features two analog outputs at 5 V, an analog input impedance of 160 kOhm, and uses an encoder connector with a 15-pin D-Sub. The unit has a control section power consumption of 8.5 W and supports an inrush current of 4 A.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The CSH01.3C-ET-EN2-NNN-CCD-S2-S-NN-FW is a plug-in control section in the CSH Advanced Controllers series from Bosch Rexroth Indramat. Installed on compatible power sections, it provides the signal-processing layer that links motion drives with higher-level PLCs in industrial automation. Field-level analog inputs, encoder feedback, and onboard diagnostics are combined so the unit can regulate speed, position, and current loops for servo axes in packaging, printing, or material-handling machines. This arrangement lets the control section exchange command values, feedback data, and status information with the drive system during coordinated machine motion.
This control section operates from a system supply of 24 VDC. Under nominal conditions, its internal electronics draw only 8.5 W, reducing panel heat load. Two differential analog inputs present an impedance of 160 kOhm, which minimizes loading on process transducers. For actuator commands, the board offers an analog output range centered on 5 V. A total of 2 analog outputs are available, allowing simultaneous reference signals for dual-channel drives or external monitoring equipment. The design keeps power-up stress low by limiting surge demand and pulse duration, which helps protect cabinet fuses and upstream power supplies. Encoder power is delivered at 5.0 V so digital feedback devices can be energized directly without external converters.
Feedback cabling terminates on a D-Sub (15-Pin) connector, and the encoder rail can supply up to 350 mA to incremental or absolute sensors, supporting long cable runs without voltage drop. The feedback interface supports encoder integration without requiring a separate supply module for low-power sensor electronics. An inrush limiter keeps power-up demand brief and helps prevent nuisance trips on supply breakers. Screened analog paths and controlled-impedance outputs help maintain signal integrity when the controller shares enclosures with switching drives and contactors.
Frequently Asked Questions about CSH01.3C-ET-EN2-NNN-CCD-S2-S-NN-FW:
Q: How many analog outputs does the CSH01.3C-ET-EN2-NNN-CCD-S2-S-NN-FW controller have?
A: The CSH01.3C-ET-EN2-NNN-CCD-S2-S-NN-FW controller has two analog outputs, each capable of outputting up to 5 V.
Q: What supply voltage does the CSH01.3C-ET-EN2-NNN-CCD-S2-S-NN-FW require?
A: This controller requires a supply voltage of 24 VDC for proper operation.
Q: What is the analog input impedance value for the CSH01.3C-ET-EN2-NNN-CCD-S2-S-NN-FW?
A: Its analog input impedance is rated at 160 kOhm, suitable for standard signal interfacing.
Q: What kind of encoder connector does the CSH01.3C-ET-EN2-NNN-CCD-S2-S-NN-FW controller use?
A: The encoder connector uses a 15-pin D-Sub interface for connection.
Q: How much power does the control section of the CSH01.3C-ET-EN2-NNN-CCD-S2-S-NN-FW consume?
A: Control section power consumption for this controller is 8.5 W.
