CSH01.1C-PB-ENS-EN2-MEM-NN-S-NN-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911310866
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
5 Minutes
2 Seconds
The Bosch Rexroth Indramat CSH01.1C-PB-ENS-EN2-MEM-NN-S-NN-FW is part of the CSH Advanced Controllers series. It is a single-axis controller that supports PROFIBUS communication, with a standard control panel and IP20 protection rating. The unit features I/O connectors at X31 and X32, a memory card slot at X7, and a width of 49.5 mm.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The CSH01.1C-PB-ENS-EN2-MEM-NN-S-NN-FW controller is produced by Bosch Rexroth Indramat and belongs to the CSH Advanced Controllers series. It is a modular drive control unit intended to coordinate servo motion in industrial automation cells and machine tools. By handling axis commands, fieldbus communication, and feedback processing, the device acts as the central logic layer between higher-level PLCs and the connected power section.
The unit is designed for single-axis operation, so its internal processor, memory, and feedback channels supervise one motor at a time. Integrated fieldbus support for PROFIBUS allows deterministic exchange of setpoints and diagnostics with distributed controllers, while the service port uses RS-232 on connector X2 for parameter upload or service access. An IP20 protection rating limits the housing to dry, cabinet-mounted environments where conductive debris and moisture are excluded. Discrete sensor and actuator lines are powered through the auxiliary bus with 24 V and 0 V connections, simplifying wiring to limit switches and relay coils. A standard front control panel provides local status LEDs and soft keys, the X7 slot accepts a removable memory card for parameter cloning, and optional encoder inputs cover IndraDyn, Hiperface, EnDat 2.1, 1 Vss, TTL, or emulated channels without adding daughterboards.
Mechanical installation is simplified by the compact envelope: the frame is 49.5 mm wide, 241 mm high, and 103 mm deep, so it can share DIN-rail space beside power inverters. All discrete I/O is landed on the dual-level terminals labeled X31 / X32, keeping signal plugs separate from the fieldbus and encoder ports. The dimensional profile also aids in maintaining airflow paths inside the cabinet, and clearances stay within standard UL spacing for 24-volt control circuitry.
Frequently Asked Questions about CSH01.1C-PB-ENS-EN2-MEM-NN-S-NN-FW:
Q: What communication protocol is available on the CSH01.1C-PB-ENS-EN2-MEM-NN-S-NN-FW controller?
A: The CSH01.1C-PB-ENS-EN2-MEM-NN-S-NN-FW controller supports communication via PROFIBUS.
Q: What protection rating does the CSH01.1C-PB-ENS-EN2-MEM-NN-S-NN-FW controller have?
A: This model is rated for IP20 protection, offering basic protection against solid objects.
Q: How many axes can the CSH01.1C-PB-ENS-EN2-MEM-NN-S-NN-FW controller manage?
A: The CSH01.1C-PB-ENS-EN2-MEM-NN-S-NN-FW is designed for a single-axis control setup.
Q: Where is the memory card slot located on the CSH01.1C-PB-ENS-EN2-MEM-NN-S-NN-FW controller?
A: This controller is equipped with a memory card slot at X7 for additional storage and configuration.
Q: What are the I/O connector options and supply voltage for the CSH01.1C-PB-ENS-EN2-MEM-NN-S-NN-FW controller?
A: Connections for I/O are provided on the X31 and X32 connectors with a 24V, 0V supply.
