The Bosch Rexroth Indramat CSH01.1C-ET-EN1-EN2-NNN-S2-S-NN-FW belongs to the CSH Advanced Controllers series and features MultiEthernet master communication and a standard control panel. It supports Safe Motion safety option at SIL2/Cat. 3 PL d, has analog input and output ratings of ±10 V, 160 kOhm and 5 V, 1 mA respectively, and is equipped with HSF/RSF and EnDat 2.1/1Vpp/TTL encoder interfaces. The controller measures 241 mm in height, 49.5 mm in width, and 103 mm in depth.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The CSH01.1C-ET-EN1-EN2-NNN-S2-S-NN-FW is a single-axis motion and logic controller from the CSH Advanced Controllers series produced by Bosch Rexroth Indramat. Within an automation cell, this unit operates as the command layer between the drive inverter and the higher-level PLC, processing encoder feedback, fieldbus telegrams, and local I/O so a servo axis can be positioned with safety functions active. A standard control panel on the front provides status LEDs and parameter keys for local access during setup and diagnostics.
The housing stands 241 mm high, 49.5 mm wide, and 103 mm deep, dimensions suited for dense DIN-rail racks in multi-axis cabinets where panel space is limited. Field networking is handled through the controller’s MultiEthernet master port, allowing EtherNet/IP, PROFINET IO, or EtherCAT communication with upstream automation equipment. Integrated Safe Motion rated at Safe Motion (SIL2 / Cat. 3 PL d) monitors speed, standstill, and direction without an external relay. Digital electronics are supplied from the bus rail with 1.1 A available for sensors, while individual digital inputs accept 24 V at 3 mA and sourcing outputs switch 24 V loads up to 0.5 A. Encoder socket 1 supports HSF or RSF signals, and encoder socket 2 accepts EnDat, 1 Vpp, or TTL formats. The enclosure depth leaves room in front of the RS-232 service port for a straight serial plug and attached cable.
An analog command channel admits ±10 V, 160 kΩ signals for speed or torque loops, while the internal DAC provides a 5 V, 1 mA analog output for transducer drive or test points. For discrete actuators, the switched output bank delivers 24 V, 0.5 A per point, and emergency chains can use the Form C contact rated at DC 24 V, 1 A. Precision feedback over the second socket is enabled by EnDat 2.1, 1 Vpp, or TTL compatibility, eliminating extra interface cards. Together with the digital I/O envelope and the relay contacts, the controller ties sensors, brakes, and gate interlocks directly to the drive safety logic without additional interface modules or extra external wiring.
Frequently Asked Questions about CSH01.1C-ET-EN1-EN2-NNN-S2-S-NN-FW:
Q: What master communication interface is supported by the CSH01.1C-ET-EN1-EN2-NNN-S2-S-NN-FW controller?
A: The CSH01.1C-ET-EN1-EN2-NNN-S2-S-NN-FW controller is equipped with a MultiEthernet master communication interface.
Q: Which encoder interface options are available on the CSH01.1C-ET-EN1-EN2-NNN-S2-S-NN-FW?
A: This controller features two encoder interfaces: HSF/RSF on the first and EnDat 2.1, 1Vpp, or TTL on the second.
Q: What safety certification does the CSH01.1C-ET-EN1-EN2-NNN-S2-S-NN-FW offer?
A: The safety option included is Safe Motion, rated at SIL2 and Cat. 3 PL d.
Q: What is the analog input specification for the CSH01.1C-ET-EN1-EN2-NNN-S2-S-NN-FW?
A: The analog input rating is ±10 V with an input resistance of 160 kOhm.
Q: What is the digital output capability of the CSH01.1C-ET-EN1-EN2-NNN-S2-S-NN-FW controller?
A: Digital outputs are rated for 24 V and can supply up to 0.5 A.
