CSH01.1C-CO-ENS-NNN-NNN-S1-S-NN-FW
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911312966
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The CSH01.1C-CO-ENS-NNN-NNN-S1-S-NN-FW is a panel-mounted advanced controller with a 24 V DC power supply. Designed by Bosch Rexroth Indramat as part of the CSH Advanced Controllers series, it features EtherCAT communication and is compatible with Rexroth IndraDrive units. It includes a Safe Torque Off function.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
For reliable motion control applications, the Bosch Rexroth Indramat CSH01.1C-CO-ENS-NNN-NNN-S1-S-NN-FW is an outstanding control module of the CSH Advanced Controllers family.
Similar to the CO connection/interface that facilitates EtherCAT communication, which is quick and effective in sharing data with other automation components, this control section type is called CSH. Both EnDAT 2.1/2.2 and HIPERFACE DSL are supported by the bundled ENS encoder interface, giving the programmer the option to select encoder feedback (for accurate speed as well as position control). Safety, the S1 safety option is implemented in this unit with Safe Torque Off (STO) and Safe Stop 1 (SS1) functions, and implemented in a single safety configuration labeled as S. Firmware is not installed in this unit, indicated as FW, and should be selected and ordered separately to suit a specific application. The unit is fully compatible with the Rexroth IndraDrive drive series and features a 24 V DC output. It has a panel mounting with operating temperatures of 0°C to 40°C (depending upon installation position and system loading).
The CSH controller can drive an encoder at the maximum frequency of 400 kHz using its EnDAT/DSL interface and has an integrated non Volatile memory that provides secure storage of parameters. Diagnostic data is well displayed using multi-color LEDs that show the system status and faults. Thermal management is performed by convection with the airflow of the drive system which is silent and maintenance free. Its protection level is rated at IP20, meaning that it can be installed within control cabinets. It can be purchased at Wake Industrial with a one-year warranty.
Frequently Asked Questions about CSH01.1C-CO-ENS-NNN-NNN-S1-S-NN-FW:
Q: What is the maximum encoder frequency supported by the CSH01.1C-CO-ENS-NNN-NNN-S1-S-NN-FW?
A: The CSH01.1C-CO-ENS-NNN-NNN-S1-S-NN-FW can handle encoder frequencies up to 400 kHz, supporting high-speed, high-precision motion control.
Q: How is thermal management handled in the CSH01.1C-CO-ENS-NNN-NNN-S1-S-NN-FW?
A: The CSH01.1C-CO-ENS-NNN-NNN-S1-S-NN-FW uses convection cooling via the IndraDrive system airflow, providing silent, maintenance-free thermal management.
Q: What communication interface does the CSH01.1C-CO-ENS-NNN-NNN-S1-S-NN-FW provide?
A: The CSH01.1C-CO-ENS-NNN-NNN-S1-S-NN-FW features a CO interface supporting EtherCAT communication for fast, efficient data exchange with automation systems.
Q: What encoder types are supported by the CSH01.1C-CO-ENS-NNN-NNN-S1-S-NN-FW?
A: It supports EnDAT 2.1/2.2 and HIPERFACE DSL encoders, enabling precise, flexible position and speed feedback for closed-loop control.
Q: What safety functions does the CSH01.1C-CO-ENS-NNN-NNN-S1-S-NN-FW offer?
A: The module includes Safe Torque Off (STO) and Safe Stop 1 (SS1) functions under the S1 safety option, providing reliable integrated safety for machine applications.
