The Bosch Rexroth Indramat CS351E-G IL is part of the CS Compact Controller Systems series and features a TFT touch screen with a 640 x 480 resolution. This controller offers an Ethernet connection using an 8-pin RJ45 connector at 10/100 Base T speeds and supports both Type A and Type B expansion slots. It provides a nominal power of 1200 VA, peak power of 4800 VA, and uses an IP54 protection type.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The CS351E-G IL is an integrated controller from Bosch Rexroth Indramat within the CS Compact Controller Systems series. It coordinates motion, I/O, and visualization from a single panel, giving automated assembly cells centralized control. By combining PLC logic, the operator interface, and field networking in one housing, the CS351E-G IL fits stations that require compact hardware and minimal cabinet space on the plant floor.
The built-in operator panel uses a TFT touch screen with a native resolution of 640 × 480 pixels, so commands and process data can be handled without an external monitor. Program execution follows IEC 61131-3, allowing ladder, structured text, and function block applications to be reused across compatible Rexroth platforms. Field connectivity includes an 8-pin RJ45 socket for 10/100 Base-T Ethernet and a serial port that supports RS-232 communication at 115 kbit/s for legacy devices. One Type B USB 2.0 device interface exchanges files at 3 Mbit/s, while three expansion slots, consisting of one Type A and two Type B positions, accept option cards for additional axis interfaces or digital I/O. Under rated load, the controller draws 1200 VA, which matches the needs of a typical single-station installation.
During short transient conditions such as motor startup or spindle clamping, the power stage can supply 4800 VA to support brief inrush demand without nuisance trips upstream. The housing has an IP54 rating, helping protect the unit against dust and oil mist in industrial environments. It also meets electromagnetic compatibility Level IV, which supports reliable operation near switching equipment and welding cells. Correct installation is vertical on a back panel, and the integrated Ethernet transceiver maintains communication over line lengths of up to 50 m. Despite the integrated power supply and display, the unit weighs 9.7 kg, which keeps handling manageable during installation.
Frequently Asked Questions about CS351E-G IL:
Q: What type of display and resolution does the CS351E-G IL controller have?
A: The CS351E-G IL features a TFT touch screen with a display resolution of 640 x 480.
Q: What Ethernet connectivity and speed does the CS351E-G IL offer?
A: This model supports Ethernet communication with an 8-pin RJ45 connector at 10/100 Base T speeds.
Q: What are the nominal and peak power ratings of the CS351E-G IL controller?
A: The CS351E-G IL controller is rated at a nominal power of 1200 VA and has a peak power capacity of 4800 VA.
Q: What is the required installation position for the CS351E-G IL controller?
A: The controller is designed for vertical installation only.
Q: What level of environmental protection does the CS351E-G IL offer?
A: This controller meets the IP54 protection standard for dust and splash resistance.
