CS351E-D NK Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: 608830281
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
Current response time:
4 Minutes
53 Seconds
The Bosch Rexroth Indramat CS351E-D NK is part of the CS Compact Controller Systems series and weighs 9.9 kilograms. This controller offers a nominal power of 1200 VA, peak power of 4800 VA, and features an LC display. It is equipped with two USB 2.0 ports, an 8-pin RJ45 Ethernet port, and is rated for IP54 protection.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
Bosch Rexroth Indramat’s CS351E-D NK controller belongs to the CS Compact Controller Systems series. It integrates power conversion, axis control, and field communication in one enclosure so a machine builder can centralize drive and logic functions. When mounted in a cabinet, the unit coordinates spindle positioning, servo motion, and peripheral I/O to automate repetitive machining, assembly, or packaging sequences on the plant floor.
The housing measures 210 × 357.6 × 245.5 mm, so it fits narrow switchgear rows while still leaving room for cable radii. Continuous consumption tops out at 1200 VA, while short load surges can reach 4800 VA, allowing coupled servo supplies to start simultaneously. An IP 54 enclosure rating guards the electronics from dust and water spray, which suits plant-floor cabinets cooled by filtered air rather than sealed climate systems. Network traffic reaches the CPU through an 8-pin RJ45 (10/100 Base-T) Ethernet port that supports deterministic messaging to PLCs and supervisory HMI stations. A passive LC display on the front panel shows status codes, and the specified vertical installation position encourages chimney airflow through the heat-sink fins.
A serial interface supports local device wiring and reaches a maximum data rate of 115 kbit/s over the RS-232 connector for field service laptops. Two front-mounted 2 × USB 2.0 Type A host ports provide removable-media logging and firmware updates, limited to the integrated 5 V, 0.5 A supply per channel. The controller can operate up to 2000 m above MSL without derating, and its mass of 9.9 kg eases panel hinge loading during maintenance. For motion circuitry, system bus signals exit on 9-pin Sub-D jumpers, a dedicated 11-pin female spindle socket, and motor-enable links that may extend 50 m during operation or 30 m when power is removed.
Frequently Asked Questions about CS351E-D NK:
Q: What type of Ethernet port does the CS351E-D NK controller use?
A: The CS351E-D NK controller features an 8-pin RJ45 Ethernet port supporting 10/100 Base-T networking.
Q: What is the allowable maximum installation altitude for the CS351E-D NK?
A: The maximum altitude for operating the CS351E-D NK controller is 2000 meters above mean sea level.
Q: How many USB host ports are available on the CS351E-D NK controller?
A: This model provides two USB 2.0 Type A host ports with 5 V DC and 0.5 A output each.
Q: What is the nominal and peak power capacity of the CS351E-D NK?
A: The CS351E-D NK offers a nominal power rating of 1200 VA and a peak power of 4800 VA.
Q: What is the protection rating of the CS351E-D NK controller?
A: This controller system is rated at IP 54 for protection against dust and water spray.
