CDB01.1C-SE-ENS-ENS-EN1-NNN-S2-S-NN-FW

  • Rated 4.4 (22 total ratings)
  • MPN: R911331253
  • Call for Expedited Shipping and Product Condition Options
The CDB01.1C-SE-ENS-ENS-EN1-NNN-S2-S-NN-FW control unit is manufactured by Bosch Rexroth Indramat. The unit utilizes SERCOS Interface as its form of master communication, and it is equipped with various interface options including Encoder Indradyn/Hiperface/1 Vpp/TLL and Encoder HSF/RSF.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

CDB01.1C-SE-ENS-ENS-EN1-NNN-S2-S-NN-FW

  • Rated 4.4 (22 total ratings)
  • MPN: R911331253
  • Call for Expedited Shipping and Product Condition Options
The CDB01.1C-SE-ENS-ENS-EN1-NNN-S2-S-NN-FW control unit is manufactured by Bosch Rexroth Indramat. The unit utilizes SERCOS Interface as its form of master communication, and it is equipped with various interface options including Encoder Indradyn/Hiperface/1 Vpp/TLL and Encoder HSF/RSF.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Sell Us Your Surplus
Have a CDB01.1C-SE-ENS-ENS-EN1-NNN-S2-S-NN-FW to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

Drive and motion control components like servo motors, gearboxes, inverters, converters, and drive controllers are parts of the high-performance Rexroth IndraDrive drive system. The drive controllers are composed of power sections and control sections. The control sections are compact units plugged into the power sections but can be ordered separately. The CDB series is a family of such control sections where the features of two digital axes are combined into one.

The CDB01.1C-SE-ENS-ENS-EN1-NNN-S2-S-NN-FW is a configurable control section in Bosch Rexroth’s CDB01 series. It is a Version 1 model whose control communication module is SERCOS III, the Ethernet-based version of SERCOS II. The communication module is suitable for applications that require high-precision motion control, and its interface corresponds to standard IEE 802.3. Other features of the CDB01 model are its two standard encoder interfaces that support encoder systems with a 12V supply voltage. These include the encoder systems of IndraDyn S MSK motors, the 5V-TTL square-wave encoder with reference track, the sin-cos encoder (1 Vpp) with Hiperface, and the sin-cos encoder (1 Vpp) with reference track.

A standard control panel on the CDB01.1C-SE-ENS-ENS-EN1-NNN-S2-S-NN-FW performs functions like setting the transmission power and transmission rate of the SERCOS module, establishing the position data reference and accessing the error memory. It plays a significant role in diagnostics and is equipped with a single-line display where pending warnings, operating states, and error diagnoses are displayed. The typical inrush current of the control section is 6A, and its maximum pulse width is 60ms. Its connection points have spring terminals and screw terminal blocks, and it supports the use of firmware. This firmware must be ordered separately. This product can be shipped globally with a one year warranty period from Wake Industrial.

  • CDB011CSEENSENSEN1NNNS2SNNFW
  • CDB01 1C SE ENS ENS EN1 NNN S2 S NN FW
  • cdb01.1c-se-ens-ens-en1-nnn-s2-s-nn-fw

CDB01.1C-SE-ENS-ENS-EN1-NNN-S2-S-NN-FW Technical Specifications

Master Communication: SERCOS Interface
Option 1: Encoder Indradyn/Hiperface/1 Vpp/TLL
Option 2: Encoder Indradyn/Hiperface/1 Vpp/TLL
Option 3: Encoder HSF/RSF
