CDB01.1C-SE-ENS-ENS-NNN-NNN-NN-S-NN-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911305634
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat CDB01.1C-SE-ENS-ENS-NNN-NNN-NN-S-NN-FW is part of the CDB Control Units series and supports two axes with both analog and digital inputs and outputs. This unit includes an RS232 serial interface, Hiperface encoder interface, and a sercos II control communication on a fiber optic link. It features a standard operator panel, relay output, and a multimedia card slot.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The CDB01.1C-SE-ENS-ENS-NNN-NNN-NN-S-NN-FW belongs to the CDB Control Units series developed by Bosch Rexroth Indramat. This plug-in control section is installed in Rexroth drive controllers to coordinate multiple servo axes, exchange motion data with higher-level PLCs, and forward status information to plant networks. By combining axis control, fieldbus communication, and service ports on one compact board, the unit streamlines cabinet wiring and setup in packaging machines, printing lines, and general factory automation.
The controller provides analog I/O channels for continuous-value commands and digital I/O points for on/off signals such as limit switches or drive-ready feedback. Motion profiles for up to 2 axes are exchanged over the deterministic SERCOS II protocol, and this traffic runs on a fiber-optic ring that is resistant to electrical noise and supports high loop speeds. These interfaces allow tight synchronization of drives while maintaining galvanic isolation from the mains. Application programs can combine cyclic position data with bit-level diagnostics so the host PLC receives complete axis status without polling extra modules.
Feedback from motors equipped with Hiperface encoders is decoded directly on the board, eliminating external converter cards. A service laptop can connect through the onboard RS-232 port for parameter access and diagnostics. For offline cloning, a front-access MultiMediaCard slot stores device parameters that can be transferred to identical units in the field. One programmable relay output lets the motion system energize brakes or interlocks when axis conditions reach a selected state. The standard operator panel provides a simple keypad and LED display for jog moves, error resets, and status review. The module does not include integrated safety technology, so it remains dedicated to motion control tasks.
Frequently Asked Questions about CDB01.1C-SE-ENS-ENS-NNN-NNN-NN-S-NN-FW:
Q: How many axes can the CDB01.1C-SE-ENS-ENS-NNN-NNN-NN-S-NN-FW control?
A: The CDB01.1C-SE-ENS-ENS-NNN-NNN-NN-S-NN-FW provides support for two axes control.
Q: What communication and link medium does the CDB01.1C-SE-ENS-ENS-NNN-NNN-NN-S-NN-FW use?
A: This model uses sercos II for control communication and utilizes a fiber optic link as the transmission medium.
Q: Does the CDB01.1C-SE-ENS-ENS-NNN-NNN-NN-S-NN-FW have analog and digital I/O support?
A: The unit is equipped with both analog and digital input/output capabilities for versatile signal management.
Q: What type of encoder interface is supported by the CDB01.1C-SE-ENS-ENS-NNN-NNN-NN-S-NN-FW?
A: Hiperface encoder interfaces are supported on this control unit.
Q: What operator panel and serial interface are available on the CDB01.1C-SE-ENS-ENS-NNN-NNN-NN-S-NN-FW?
A: A standard operator panel and RS232 serial interface are included with this model.
