CDB01.1C-SE-EN2-EN2-EN1-EN1-NN-S-NN-FW
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911310561
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
-
In-Stock, Ships 3-5 Days
The CDB01.1C-SE-EN2-EN2-EN1-EN1-NN-S-NN-FW control unit is manufactured by Bosch Rexroth Indramat. The unit utilizes SERCOS Interface as its form of master communication, and it is equipped with various interface options including Encoder EnDat 2.1/1Vpp/TLL and Encoder HSF/RSF.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The Bosch Rexroth CDB01.1C-SE-EN2-EN2-EN1-EN1-NN-S-NN-FW is a CDB series basic universal type control section. Bosch manufactures multiple types of control sections for its IndraDrive product line. The different types of control sections differ in the number of slots for plug in modules, the available interfaces and the cycle times or switching frequencies. The CDB01.1C-SE-EN2-EN2-EN1-EN1-NN-S-NN-FW has five slots. Four of the slots are occupied. Slot 1 and 2 both come with a pre-installed encoder EnDat 2.1 module. Slot 3 and 4 both come with a pre-installed encoder HSF / RSF module. Slot 5 on the CDB01.1C-SE-EN2-EN2-EN1-EN1-NN-S-NN-FW is reserved for a safety module and is unoccupied. An integrated RS-232 interface is available on the control section. This interface allows serial communication with other serial enabled devices. The master communication interface on the CDB01.1C-SE-EN2-EN2-EN1-EN1-NN-S-NN-FW is SERCOS.
