CDB01.1C-PB-EN2-EN2-EN1-EN1-S2-S-NN-FW Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911341010
The Bosch Rexroth Indramat CDB01.1C-PB-EN2-EN2-EN1-EN1-S2-S-NN-FW is part of the CDB Control Units series and operates with a base supply voltage of DC 24 V and base power consumption of 9 W. It features PROFIBUS control communication, a single-line display control panel, and encoder slots that support EnDat 2.1, 1 Vpp, and 5 V TTL. This unit offers Safe Motion safety functions with a D-Sub 9-pin connector and a safety output rating of 24 V at 0.5 A.
Internal Product Review
The CDB01.1C-PB-EN2-EN2-EN1-EN1-S2-S-NN-FW is a Bosch Rexroth Indramat CDB control unit that stands out with PROFIBUS communication and Safe Motion functionality. Encoder slots 1-2 support EnDat 2.1, 1 Vpp, and 5 V TTL feedback, while slots 3-4 handle resolver and HSF signals for flexible feedback integration. The 24 V DC supply and 9 W base power consumption make the control unit a strong choice for efficient precision motion systems.
Have a part to sell?
Wake Industrial Warranty
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The CDB01.1C-PB-EN2-EN2-EN1-EN1-S2-S-NN-FW belongs to the CDB Control Units series from Bosch Rexroth Indramat. It is a configurable control section that plugs into the modular drive system and coordinates motion axes, diagnostic feedback, and integrated safety functions. By combining sensor interfaces, fieldbus communication, and logic resources, the unit acts as the central intelligence for servo inverter power sections used in automated assembly lines, packaging equipment, and material-handling stations.
At the power input, the board operates from a base supply of DC 24 V, a low-voltage level that simplifies cabinet wiring and allows the device to remain active during mains dropouts. Under idle conditions, the logic electronics draw only 9 W, reducing heat dissipation and conserving auxiliary power in multi-axis installations. Command data exchange with higher-level PLCs takes place through PROFIBUS, so deterministic cyclic telegrams can reach every drive without additional gateways. The first encoder channel supplies high-speed feedback devices with 250 mA at 8 V, and it excites the resolver winding at 4 kHz. These values provide sufficient signal amplitude and bandwidth for precise position capture even at elevated motor speeds.
