CDB01.1C-PB-EN1-EN1-EN2-EN2-S1-S-NN-FW Bosch Rexroth Indramat
MPN: R911306867
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat CDB01.1C-PB-EN1-EN1-EN2-EN2-S1-S-NN-FW is a control unit in the CDB Control Units series. It features an analog input range of ±10 V and an analog output signal of 5 V at 1 mA. The unit provides digital input and output signals at 24 V, with a maximum power consumption of 36 W and an inrush current of 6 A.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
Bosch Rexroth Indramat manufactures the CDB01.1C-PB-EN1-EN1-EN2-EN2-S1-S-NN-FW, a plug-in controller from the CDB Control Units series. This card installs in IndraDrive power sections and coordinates motion, safety, and feedback loops for servo axes in automated machinery. By providing analog, digital, and encoder interfaces on one compact module, the unit links field signaling to the drive processor and allows parameterization through the front service port. This arrangement lets one module handle command processing, feedback evaluation, and local I/O exchange without additional interface cards. Its purpose is to translate plant-level commands into the regulated voltage and current values required for precise motor operation.
The control unit processes command voltages up to ±10 V, and the analog input path presents a high impedance of 160 kΩ so source devices are not loaded. A dedicated analog output can source 5 V / 1 mA for reference feedback to external PLC cards. Twelve digital inputs accept 24 V / 3 mA signals, while four transistor outputs deliver 24 V / 0.5 A for actuator coils or status lamps. Overall heat dissipation remains within 36 W, permitting fanless operation inside the drive rack. Encoder socket EN1 supplies 8 V for Hall sensor feeds and 18.2 Vpp for resolver excitation, whereas EN2 provides 5.0 V with 350 mA to power incremental encoders. These separate interface paths allow the module to exchange feedback and control signals with external hardware without requiring added converter stages.
During power-up, the drive backplane can draw an inrush of 6 A, so upstream fusing must tolerate this brief surge. Control pulses arriving on the fast inputs can be recognized with widths up to 60 ms, which supports slower sensor edges used in safety circuits. The S1 terminal can supply auxiliary sensors with 1.6 A, and its dedicated safety relay provides a 24 V DC / 0.5 A output through contacts rated at 24 V DC / 1 A for downstream interlocks. This arrangement supports connected sensors and low-voltage interlock devices from the same control platform. That helps keep external safety wiring organized within the drive system.
Frequently Asked Questions about CDB01.1C-PB-EN1-EN1-EN2-EN2-S1-S-NN-FW:
Q: What is the analog input voltage range supported by the CDB01.1C-PB-EN1-EN1-EN2-EN2-S1-S-NN-FW control unit?
A: The CDB01.1C-PB-EN1-EN1-EN2-EN2-S1-S-NN-FW has an analog input voltage range of ±10 V.
Q: What is the maximum power consumption of the CDB01.1C control unit?
A: This model features a maximum power consumption of 36 W during operation.
Q: What is the analog input resistance of the CDB01.1C-PB-EN1-EN1-EN2-EN2-S1-S-NN-FW?
A: The analog input resistance on this unit is rated at 160 kΩ.
Q: What is the digital output signal specification for the CDB01.1C-PB-EN1-EN1-EN2-EN2-S1-S-NN-FW?
A: The digital output signal provided is 24 V at a maximum of 0.5 A.
Q: What is the inrush current rating of the CDB01.1C control unit?
A: The inrush current for this model reaches up to 6 A.
