BTV20.3EA-56B-45C-D-FW
Wake Industrial LLC is not an authorized distributor of this product.
- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The BTV20.3EA-56B-45C-D-FW is an operator panel manufactured by Bosch Rexroth Indramat. Included in the BTV20 Machine Operator Panels series, it features a 12.1-inch color TFT display with a resolution of 800 x 600 pixels. The panel supports RS232, RS485, Profibus, and CAN interfaces and has an IP65 front protection rating.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
For demanding industrial control applications, the Bosch Rexroth Indramat BTV20.3EA-56B-45C-D-FW is an industrial-grade machine operator panel.
Users who need to monitor intricate machinery and automated systems can see clear, detailed images thanks to its 12.1-inch color TFT panel with 800 x 600 pixel resolution. Driven by an Intel-compatible embedded CPU, this panel packs good performance on HMI tasks, and its expandable RAM and Flash memory options enable flexibility to meet rising application demands. The unit has built-in a variety of industrial communication interfaces such as RS232, RS485, Profibus, and CAN, which users will find most adaptable to different control architectures and legacy equipment. The integrated feature of the membrane keyboard is calibrated to provide feedback in the form of its sense of touch as well as longevity in a hostile environment. Feedback is seamless and highly dependable, such that operators can easily operate on machine systems without using peripheral inputs.
The structure is designed with an impact-resistant aluminum front panel and steel rear enclosure to provide increased structural support. Operating on 24 V DC, the panel is energy efficient. It also features a passive, fanless cooling design that requires no maintenance and is silent. Its IP65 front protection and IP20 backside are suitable to panel-mount installations in safe industrial cabinets. It offers a CompactFlash Memory card, used as storage as well as upgrading the firmware easily, making it easier to manage software and data backup. The unit is about 5.5 kg and functions within the ambient temperatures of 0°C to +50°C reliably. It can be purchased at Wake Industrial with a one-year warranty.
Frequently Asked Questions about BTV20.3EA-56B-45C-D-FW:
Q: What type of display does the BTV20.3EA-56B-45C-D-FW offer?
A: The BTV20.3EA-56B-45C-D-FW features a 12.1-inch TFT color screen with 800 x 600 resolution, offering clear, detailed visuals for machine monitoring.
Q: Which communication interfaces are built into the BTV20.3EA-56B-45C-D-FW?
A: It includes RS232, RS485, Profibus, and CAN interfaces, making it highly adaptable to a wide range of industrial control systems.
Q: What kind of storage and memory options does the BTV20.3EA-56B-45C-D-FW support?
A: It includes expandable RAM, Flash memory, and a CompactFlash card slot for firmware updates and data backup.
Q: How is the BTV20.3EA-56B-45C-D-FW protected in industrial environments?
A: It offers IP65 protection on the front and IP20 on the rear, with a rugged aluminum and steel enclosure ideal for panel-mounted use in cabinets.
Q: How is the BTV20.3EA-56B-45C-D-FW powered and cooled?
A: The unit runs on 24 V DC and uses a fanless passive cooling system, ensuring quiet, maintenance-free operation.
