When it comes to automation design and deployment, Rexroth Indramat is reputed for incorporating the most up-to-date innovations into its processes. The company manufactures the BTA20 units as part of its extensive line of high-end devices. The BTA20 product group consists of a fully customizable machine control panel intended to be used in combination with BTV20 visualization panels. At 2.1 kg, the BTA20.2-BA-ZP-NA-BS belongs to the BTA20 series, and its width, height, and depth are 407 mm, 169 mm, and 119 mm. The primary color of this unit is light gray.
The BTA20.2-BA-ZP-NA-BS is equipped with an NA-type emergency stop module, and it has a red key, two (2) white illuminated keys, a key switch, and a mushroom key (yellow). In addition, this unit has a BA blank module. The BTA20.2-BA-ZP-NA-BS is capable of dissipating up to 10 W of heat. It communicates with the linked BTV20 panel via an INTERBUS-S module. The current consumption of this equipment is max. at 1 A.
At an altitude of 1500 m, the pressure gradient of this unit is typically between 860 - 1060 hPa, depending on the model. Additionally, the optimum temp of the BTA20.2-BA-ZP-NA-BS during operation is 5 - 45 °C. The average temp. of this device during its transportation is between -20 - 60 °C. As with other automation products from Rexroth Indramat, the BTA20.2-BA-ZP-NA-BS operates reliably and safely. Also, it is only meant for use in line with the specifications and operating conditions declared by the manufacturer. Prior to installation and commissioning, the requirements for the appropriate use of this unit must be satisfied. Furthermore, if any faults are found on the BTA20.2-BA-ZP-NA-BS, it should not be mounted.
