The Bosch Rexroth Indramat BTA08.1-NN is part of the BTA08 Machine Control Boards series and features a front panel made from aluminum with a chemically resistant polyester film surface cover. This control board supports eight mounting positions, has a protection rating of IP65 with built-in elements, and weighs 0.8 kg. It is designed with a control element diameter of 22.5 mm, cutout size of 375 x 75 mm, and can operate at altitudes up to 1500 meters.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The BTA08.1-NN belongs to the BTA08 Machine Control Boards series developed by Bosch Rexroth Indramat. It is a front-panel control board intended for operator stations on factory machinery, where pushbuttons, indicator lamps, and selector switches can be grouped on one modular plate that seals to the enclosure door. By using standardized mounting points for machine-side interface components, the board helps keep cabinet wiring organized and keeps the operating area clear and consistent. This layout supports orderly integration of door-mounted controls in automated production equipment.
The panel is drilled to accept control elements with a diameter of 22.5 mm, and these devices pass through a rectangular cutout measuring 375 × 75 mm. A rigid aluminum faceplate resists deformation during repeated use. The panel provides 8 mounting positions, and each location uses press-in M5 nuts so accessories can be secured without extra brackets. When fully populated with built-in switches and lamps, the assembly maintains a protection rating of IP65, which helps keep dust and water spray away from internal wiring. Two label strips identify the installed functions, and two rear insert openings allow cable entry from inside the control cabinet without removing the complete board.
An external footprint of 407 × 110 × 4 mm allows the plate to fit standard enclosure doors while leaving clearance for nearby hardware. With a mass of only 0.8 kg, the board adds little load to light-gauge sheet-metal panels and helps preserve smooth door movement. It can be installed at elevations up to 1500 m without derating. The working face is laminated with a chemically resistant polyester film that tolerates cleaning agents commonly used in food, packaging, and general assembly environments.
Frequently Asked Questions about BTA08.1-NN:
Q: How many mounting positions are available on the BTA08.1-NN control board?
A: The BTA08.1-NN provides 8 mounting positions for installing control elements.
Q: What material is used for the front panel of the BTA08.1-NN?
A: This front panel is made from aluminum, offering a durable material construction.
Q: What is the protection rating of the BTA08.1-NN machine control board?
A: The protection rating is IP65 when built-in elements are installed.
Q: What type of surface cover does the BTA08.1-NN feature?
A: The surface is covered with chemically resistant polyester film.
Q: What is the maximum operating altitude for the BTA08.1-NN board?
A: This panel supports operation at altitudes up to 1500 meters above sea level.
