ADF132D-B05TB1-AS03-A2S1

  • Rated 4.4 (15 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911267342
  • Call for Expedited Shipping and Product Condition Options
The ADF132D-B05TB1-AS03-A2S1 Main Spindle motor is a part of the ADF series manufactured by Bosch Rexroth. This motor operates with its Output Connector on Side B, Spindle bearing, a High-resolution motor feedback type, and is Not Equipped with a holding break.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

ADF132D-B05TB1-AS03-A2S1

  • Rated 4.4 (15 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911267342
  • Call for Expedited Shipping and Product Condition Options
The ADF132D-B05TB1-AS03-A2S1 Main Spindle motor is a part of the ADF series manufactured by Bosch Rexroth. This motor operates with its Output Connector on Side B, Spindle bearing, a High-resolution motor feedback type, and is Not Equipped with a holding break.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Sell Us Your Surplus
Have a ADF132D-B05TB1-AS03-A2S1 to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

Designed with durability and quality in mind, the ADF132D-B05TB1-AS03-A2S1 motor is made by Rexroth Indramat can stand up to a broad spectrum of industrial applications including exceptional conditions such as extreme thermal and electrical demands associated to speed and torque. Having a renowned successful industrial service in multidimensional applications of textile, printing, CNC machining and general engineering machines these motors are now an integral component of industrial enterprises. The ADF132D-B05TB1-AS03-A2S1 motor are the optimum selection for all applications in power range of 36 kilowatts. When used with the Indramat high-tech motor drive controllers these motors features broad speed ranges and long durable field life.

Motors are designed to flange mounted with easy installation. The Power connector is positioned on the upward side of the motor. Motors provide long maintenance free service life, as it follows induction principle and is made with liquid cool technique. The coolant inlet and outlet connection is located on ‘B’ side of the motor. The motor is designed without holding brakes and feedback signals from motor to the drive controller is based on high resolution encoder motor feedback mechanism.

The ADF132D-B05TB1-AS03-A2S1 motor possesses a plain output shaft without sealing rings. The nominal torque is 229Nm with nominal speed of 1500 min-1. Motor operates on input voltage of 380V and constant current of 85 amperes. For safe and worthy operation, the ambient temperature of 0° to 45° C must be maintained for accuracy of the motor feedback. The protection and safety of motor is standardize as per DIN40050, providing protection against moving parts, penetration by extrinsic objects and water. External body of motor is painted so that to withstand weathering conditions. The permissible ambient storage temperature is -25° to 85°C. This unit can be shipped globally with a one-year warranty period from Wake Industrial.

ADF132D-B05TB1-AS03-A2S1 Documents

  • ADF132DB05TB1AS03A2S1
  • adf132d-b05tb1-as03-a2s1
  • ADF132D-BO5TB1-ASO3-A2S1

ADF132D-B05TB1-AS03-A2S1 Technical Specifications

Bearing: Spindle
Holding Brake: Not Equipped
Motor Feedback: High-resolution
Output Connector: Side B
