2AD180C-B35OB2-BS01-B2N1
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911255010
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The 2AD180C-B35OB2-BS01-B2N1 three-phase induction motor features a frame size of 180, IP65 protection class, and a peak torque of up to 350 Nm. Part of the 2AD 3-Phase Induction Motors series by Bosch Rexroth Indramat, it delivers rated speeds up to 3000 rpm and utilizes cooling method OB2.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
As a high-performance industrial automation motor that is part of the well-established 2AD series, the Bosch Rexroth Indramat 2AD180C-B35OB2-BS01-B2N1 is distinguished by its durability.
This motor has a powerful footprint with 180 a frame size, and a height which is 180 mm. The length of the motor is marked as C, which is usually more supportive of higher power ratings and the torque rating in the series. The mounting is taken care of through the B35 configuration-flange and foot mount, and this provides the flexibility of installation in different machine configurations. The air-cooling system described by the code OB2 is called the blower cooling; it ensures constant thermal control in the continuous-duty mode. Mechanical option BS01 and feedback type B2N1 are included in the motor, which mostly implies closed-loop performance and integration of servo feedback in order to achieve accurate control. Depending on the kind of version, this motor's rated output typically ranges from 22 to 31 kW. It is suited for a variety of commercial uses that value consistent power and appropriate voltage needs since its nominal voltage of 400 V is often made accessible as an alternating current.
The rated speed is 3000 rpm, giving it powerful performance in most of the high-speed applications. The continuous stall torque is roughly 140 Nm, the peak torque is up to 350 Nm, and it is well suited to tackle tough loads or high acceleration curves. It is rated as thermal class F, meaning that the motor has a higher thermal performance when it is subjected to a higher operating temperature without experiencing a reduction in performance. IP65 Protection rating means that it is fully dustproof and water jet proof, making it ideal in harsh industrial settings where reliability above all others is a necessity.
Frequently Asked Questions about 2AD180C-B35OB2-BS01-B2N1:
Q: What torque and speed performance does the 2AD180C-B35OB2-BS01-B2N1 motor offer?
A: This motor delivers a continuous stall torque of approximately 140 Nm and can reach peak torque up to 350 Nm, with a rated speed of 3000 rpm.
Q: How is the 2AD180C-B35OB2-BS01-B2N1 motor cooled?
A: It uses an axial blower cooling system (OB2) to maintain thermal stability during continuous-duty operation.
Q: What type of feedback system does the 2AD180C-B35OB2-BS01-B2N1 motor use?
A: The motor integrates a servo-compatible feedback system (B2N1), supporting closed-loop control for accurate motion response.
Q: What are the mounting options for the 2AD180C-B35OB2-BS01-B2N1 motor?
A: It features a B35 mounting style, which includes both flange and foot mounts for versatile machine integration.
Q: Is the 2AD180C-B35OB2-BS01-B2N1 suitable for tough industrial environments?
A: Yes, with an IP65 protection rating and thermal class F insulation, it’s built for high heat and harsh conditions without sacrificing performance.
