2AD160C-B35OB1-DD07-B2V1
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911284135
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The 2AD160C-B35OB1-DD07-B2V1 is a synchronous AC servo motor with a frame size of 160 mm and rated power of 46 kW. Manufactured by Bosch Rexroth Indramat and part of the 2AD 3-Phase Induction Motors series, it features flange and foot B35 mounting and IP65 protection. The motor operates at 2000 rpm with surface cooling.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The 2AD160C-B35OB1-DD07-B2V1 is a precision motor built for industrial automation. It provides regulated speed and torque to enhance performance in systems that require controlled motion. The motor’s construction is enhanced for thermal efficiency with a mounted fan for self-cooling and high-temperature windings. This thermal reliability allows the motor to remain reliable under sustained operation and dynamic loads. The frame of the motor is built to ensure high torque density in motion processes that demand robust mechanical output. This unit is IP65-rated so use in harsh environments does not compromise performance.
This motor can sustain a torque of 220 Nm when operating under standard loads, facilitating efficient handling of loads. It also offers ample mechanical power to drive heavy-duty machinery, with a nominal output of 46 kW. The motor can maintain stable torque transfer to the connected machinery for speeds of up to 6000 rotations per minute. It keeps track of velocity and positioning data via built in digital servo feedback that incorporates a multiturn absolute encoder. This advanced feedback system ensures that real-time adjustments can be made to meet the desired parameters for the specific application. The shaft for output on this model is keyed, allowing secure attachment to other equipment.
The 2AD160C-B35OB1-DD07-B2V1 offers a wide operating temperature tolerance. It can perform reliably in standard industrial conditions provided ambient conditions do not go above 45°C or fall below 0°C. The motor is built to support either foot installation or flange mounting, depending on system configurations. It has electrical connectors in the form of a terminal box that are positioned on its B-side. This provides easy access for cabling when installing the motor, ensuring additional adapters are not required for power connection.
Frequently Asked Questions about 2AD160C-B35OB1-DD07-B2V1:
Q: Is the 2AD160C-B35OB1-DD07-B2V1 equipped with an encoder?
A: Yes, the 2AD160C-B35OB1-DD07-B2V1 motor comes with an integral encoder that ensures enhanced positioning accuracy during operation.
Q: What is the rated torque for the 2AD160C-B35OB1-DD07-B2V1?
A: The 2AD160C-B35OB1-DD07-B2V1 generates a continuous torque of 220 Nm, ensuring stable performance under varied loads.
Q: Is the 2AD160C-B35OB1-DD07-B2V1 capable of delivering high speeds?
A: Yes, the 2AD160C-B35OB1-DD07-B2V1 can reach a peak speed of 6000 rpm, providing ample capacity for high-speed processes.
Q: Does the 2AD160C-B35OB1-DD07-B2V1 support foot mounting?
A: Yes, the 2AD160C-B35OB1-DD07-B2V1 is constructed to be installed by its base / foot or using a flange interface depending on setup and user preference.
Q: What is the rated current draw for the 2AD160C-B35OB1-DD07-B2V1?
A: The 2AD160C-B35OB1-DD07-B2V1 is rated for 109 A, enabling it to handle power-intensive applications effectively.
