2AD160C-B35OB1-BS01-B2V1
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911245780
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The 2AD160C-B35OB1-BS01-B2V1 induction motor features a rated current of 84 amps, a rated voltage of 400 volts, a power output of 45 kW, and a cooling method via an open blower. Part of the 2AD 3-Phase Induction Motors series by Bosch Rexroth Indramat, it boasts IP23 protection and a maximum speed of 3000 rpm.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The AC Induction Motor with part number 2AD160C-B35OB1-BS01-B2V1 from Bosch Rexroth Indramat works to regulate speed. The company showcases high expertise in precision drive technology and reliable industrial automation solutions.
The 2AD160C-B35OB1-BS01-B2V1 induction motor’s bearings are integrated to support smooth operation at heavy-duty load conditions. It delivers 37 kW power output with a torque rating of 236 Nm at a continuous speed of 6000 rpm. Its cooling is achieved using an axial blower system that ensures reliable heat dissipation under extended operation. The configuration does not include a holding brake which aids in making it suited for continuous drive tasks. The unit comes with a feedback system that is managed through a high-resolution feedback device by allowing precise control for automation and process systems. The motor length code is specified as C and the size code is defined as 160. The mounting is provided with a flange and foot arrangement by enabling stable integration in machinery assemblies. Its shaft type is built without a shaft seal and is balanced with the complete key. This feature further aids in reducing vibration and ensuring uniform rotation.
The 2AD160C-B35OB1-BS01-B2V1 induction motor’s power connection is directed to Side B with a terminal box connection type and is positioned at the top for accessible cabling. The shaft end on Side B is not present and its vibration grade is marked as R to meet industrial standards. The operating temperature range is between 0 and 40 degrees Celsius. The unit mainly consumes a current rating of 90 A with a thermal time constant of 65 minutes which allows it to withstand prolonged heating cycles without performance loss.
Frequently Asked Questions about 2AD160C-B35OB1-BS01-B2V1:
Q: What torque does motor 2AD160C-B35OB1-BS01-B2V1 provide?
A: The motor delivers 236 Nm torque at 6000 rpm speed, ensuring reliable operation in heavy-duty industrial applications requiring consistent drive performance.
Q: Which cooling method is used in motor 2AD160C-B35OB1-BS01-B2V1?
A: The cooling is achieved through an axial blower system, providing efficient airflow across the housing for stable thermal control under continuous load conditions.
Q: What is the continuous power rating of motor 2AD160C-B35OB1-BS01-B2V1?
A: The motor operates at 37 kW continuous power, making it suitable for industrial machinery applications requiring reliable energy conversion and efficient drive operation.
Q: What mounting type is offered in motor 2AD160C-B35OB1-BS01-B2V1?
A: It features flange and foot mounting, enabling stable installation in machinery frameworks with flexibility for multiple mechanical integration requirements.
Q: How is the feedback handled in motor 2AD160C-B35OB1-BS01-B2V1?
A: A high-resolution motor feedback device is integrated, ensuring accurate position and speed monitoring for advanced control within automation systems.
