Product Description:

The 8LSA35.EA060D000-0 belongs to the 8LS Synchronous Motors series produced by B&R Automation. The 8LSA designation indicates a standard configuration without a reinforced bearing. As a three-phase synchronous motor, it delivers constant torque for coordinated motion axes, while length code 5 indicates the active stack size used for medium-power machine cells. By omitting an internal holding brake and an oil seal, the model is suited for applications that already provide external load locking and operate in clean environments.

The motor reaches a rated speed of 6000 rpm, enabling high-throughput positioning on packaging lines and pick-and-place gantries. Rotor position feedback is handled by an Inductive EnDat encoder that communicates through EnDat version 2.1, allowing absolute position transmission without battery maintenance. Thermal management relies on self-cooling with free circulation, so heat is removed through the housing surface without forced airflow or liquid jackets. A flange face measuring 91.3 mm provides the reference plane for rigid attachment to machine frames and aligns accurately with planetary gearboxes. Power, signal, and shield conductors terminate on a single rugged connector, which reduces cable routing complexity in compact installations.

Cable egress is facilitated by an angled swivel connection direction that can be rotated to lessen strain inside compact enclosures. The stator body incorporates a mounting flange, so no foot adapters or additional brackets are required for installation. A smooth shaft allows backlash-free coupling with clamping hubs, and the encoded feedback chain is completed by a resolution of 19/0 bits for single-turn and multi-turn information. Because the encoder supports single-turn capability, the drive retains absolute position within one revolution, and after power-up the control system needs only one mechanical reference move if multi-turn tracking is required.
