8LSA35.DB060S200-3
Wake Industrial LLC is not an authorized distributor of this product.
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
-
In-Stock, Ships 1-2 Days
The 8LSA35.DB060S200-3 is a synchronous servo motor with a rated torque of 5.2 Nm and a peak speed of 3000 RPM. Manufactured by B & R Automation as part of the 8LS Synchronous Motors series, it operates at a rated voltage of 400 V. This motor features an IP65 protection class and Hiperface DSL feedback.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The 8LSA35.DB060S200-3 Synchronous Motor from the manufacturer B & R automation is developed for industrial automation. It contains a brake having a mass of 1.09 kilograms. Brake assists in regulating the operations of stopping functions in machines. The motor under consideration has a nominal torque of 1.6 newton meters.
The electrical time parameter of the 8LSA35.DB060S200-3 synchronous motor is 5.1 milliseconds. This enables rapid reaction of electrical control signals. The nominal speed of 8LSA35.The DB060S200-3 synchronous motor refers to 6000 revolutions per minute. This speed is appropriate for multiple applications that use mid-range operation speed. The highest torque that can be produced by the motor is 9.2 Newton-meters. The torque of the motor stall is equal to 2.3 Newton-meters. The stator inductance is 15.6 millihenry. This allows for effective current control upon its operation of the motor. This motor has a rated output on the nominal of 1005 watts. The resistance of the stator of the 8LSA35.DB060S200-3 synchronous motor is 3.02 ohms. This opposition limits the losses due to electricity in the windings of the motor. The thermal time constant of the motor equals 34 minutes. The constant of the torque of the motor is 0.73 newton meters per ampere.
The voltage constant of 8LSA35.DB060S200-3 synchronous motor is 43.98 volts/1000 rpm. This gives a proper voltage feedback for speed monitoring. This motor has a maximum speed at the rate of 9000 revolutions per minute. The moment of inertia is 0.9 kilograms centimeters squared. This ensures easy acceleration and deceleration. The nominal value of the current rating is 2.2 amperes. The motor is 4.4 kilograms in weight minus the brake. The stall current rating is 3.2 A. The motor has been designed with 4 4-pole pairs. At this motor, the maximum amount of current allowed is 13.6 amperes.
Frequently Asked Questions about 8LSA35.DB060S200-3:
Q: How does thermal time constant help 8LSA35.DB060S200-3 Motor?
A: The 34-minute thermal time constant in 8LSA35.DB060S200-3 Motor ensures stable operation during extended duty cycles.
Q: How does 8LSA35.DB060S200-3 Motor handle speed variations?
A: 8LSA35.DB060S200-3 Motor maintains stable performance across speeds up to 9000 rpm without losing torque consistency.
Q: What benefit does braking system offer in 8LSA35.DB060S200-3 Motor?
A: The braking system in 8LSA35.DB060S200-3 Motor provides controlled stopping, increasing operational safety in automated machinery.
Q: Why use 4-pole pairs in 8LSA35.DB060S200-3 Motor?
A: Four-pole pairs in 8LSA35.DB060S200-3 Motor improve positional control, enhancing precision in industrial automation processes.
Q: Why is electrical time constant critical in 8LSA35.DB060S200-3 Motor?
A: 5.1 ms electrical time constant in 8LSA35.DB060S200-3 Motor enables quick response to control signals for precise motor control.
