8LSA35.DA030S100-3
Wake Industrial LLC is not an authorized distributor of this product.
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
-
In-Stock, Ships 1-2 Days
The 8LSA35.DA030S100-3, part of B & R Automation's 8LS Synchronous Motors series, is a self-cooled synchronous servo motor with a 100 mm flange size. It features a rated voltage of 400 V, a rotatable connector-type connection, and an IP65 protection class. The motor achieves a max speed of 6000 rpm.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
B & R Automation manufactures the 8LSA35.DA030S100-3 Synchronous Motor. This motor is made in the form of a three-phase synchronous motor for industrial automation. It runs at a nominal speed of 3000 rpm. It has a 4-pole pair motor, which is used for accurate control. It offers a nominal torque of 2.1 Nm. The nominal output power of the motor is 660W.
The 8LSA35.DA030S100-3 synchronous motor operates with 1.4A of nominal current. Under the condition of continuous operation, it is reliable. The stall torque of this motor is 2.3 Nm. The stall current needed is 1.6 A. This enables the motor to stay in place when not in rotation. The torque limit that can be provided by this motor is 9.2 Nm. The maximum current of the motor is 6.8 A. This allows the motor to cope with increased load demands for a short period. The maximum speed of this motor goes up to 9000 rpm. This speed operation range enables it to operate in different applications. The torque constant of the 8LSA35.DA030S100-3 synchronous motor is in the order of 1.45 Nm/A. This ensures easy torque regulation in the operation of machines.
The 8LSA35.DA030S100-3 synchronous motor has a voltage constant of 87.96 V at 1000 rpm. This gives a stable electrical feedback for speed regulation. The motor has a brake having a holding torque of 0 Nm. Mass of the brake is 1.09 kg. The brake is a stopping device and not a load-holding device. The motor has a simple solution for connections, i.e., a single cable. This makes wiring less complex during installation. Swivel SCS is used as a connection direction for the flexible routing of cable. Its small body and cable system minimize the installation space.
Frequently Asked Questions about 8LSA35.DA030S100-3:
Q: Why does 8LSA35.DA030S100-3 Motor use single cable connection?
A: 8LSA35.DA030S100-3 Motor simplifies wiring with a single cable, reducing installation time and potential connection errors significantly.
Q: What benefits does Swivel SCS offer in 8LSA35.DA030S100-3 Motor?
A: Swivel SCS in 8LSA35.DA030S100-3 Motor allows flexible cable routing, minimizing mechanical stress on wiring during installation.
Q: How does 8LSA35.DA030S100-3 Motor manage thermal stress?
A: 8LSA35.DA030S100-3 Motor is designed to dissipate heat effectively, maintaining performance under continuous operational loads.
Q: What role does voltage constant play in 8LSA35.DA030S100-3 Motor?
A: The 87.96 V/1000 rpm voltage constant in 8LSA35.DA030S100-3 Motor provides consistent feedback for precise speed control.
Q: Why is 4-pole design used in 8LSA35.DA030S100-3 Motor?
A: 4-pole design in 8LSA35.DA030S100-3 Motor enhances positional accuracy, critical for precision industrial automation tasks.
