The B & R Automation 8LSA34.EA060D100-0 is a three-phase synchronous motor from the 8LS Synchronous Motors series, configured as standard with no reinforced bearing. It features a flange dimension of 91.3 mm, self-cooling principle with free circulation, and a mounting flange. The motor includes an inductive EnDat encoder technology, supports a rated speed of 6000 rpm, and has an angled connector with no holding brake or oil seal.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The 8LSA34.EA060D100-0 is a three-phase synchronous servo motor produced by B&R Automation within the 8LS Synchronous Motors series. Supplied under the internal designation 8LSA, the unit is intended for positioning and speed-controlled duties in automated machinery, where compact flange mounting and electronic feedback support tight motion loops. By integrating a flange interface directly onto the housing, the motor can be fastened to gearboxes or machine frames without additional brackets, making it a straightforward drive element for packaging, material-handling, or small-robot axes.
The drive reaches a rated speed of 6000 rpm, so controllers can command high cycle rates before field weakening becomes necessary. A flange dimension of 91.3 mm sets the mechanical envelope and the bolt circle used during installation. Rotor position is supplied by an Inductive EnDat sensor, a non-contact system selected for resistance to vibration and dust. Data transmission follows EnDat version 2.1, enabling digital identification and automatic calibration at power-up. The feedback depth is 19/0, which corresponds to 19 single-turn bits and no multiturn register. Length code 4 indicates the stator stack height, which sets the continuous torque level. The motor is supplied without a holding brake, so static load support must come from the drive amplifier.
Cabling exits through an angled swivel connector that can be rotated for strain-relief routing, and power plus feedback share a single molded connector body. Thermal management uses self-cooling through free circulation, eliminating external blowers in tight cabinets. The shaft is machined with a key to simplify coupling to pulleys or pinions, and an oil seal is not included. Mounting occurs on the integral flange, and the motor uses a three-phase synchronous electrical design for constant torque across the servo bandwidth. Single-turn capability suits applications that index within one revolution, while the absence of an internal brake keeps inertia low for fast reversal cycles.
Frequently Asked Questions about 8LSA34.EA060D100-0:
Q: What type of connection direction does the 8LSA34.EA060D100-0 motor use?
A: This model features an angled (swivel) connector for electrical connection.
Q: How is the 8LSA34.EA060D100-0 motor cooled?
A: The 8LSA34.EA060D100-0 operates with self-cooling and free air circulation.
Q: What encoder technology is built into the 8LSA34.EA060D100-0?
A: Inductive EnDat encoder technology is integrated into this motor model.
Q: Is a holding brake present on the 8LSA34.EA060D100-0 synchronous motor?
A: This motor does not include a holding brake.
Q: What type of shaft end is provided with the 8LSA34.EA060D100-0 motor?
A: The shaft end of this model includes a key for secure mechanical coupling.
