The 8LSA25.D8060S100-3 synchronous servo motor features a frame size of 25 (250 mm flange), a rated speed of 3000 rpm, a cooling method that is self-ventilated, and a feedback system using a single cable absolute encoder. Part of the 8LS Synchronous Motors series by B & R Automation, it delivers 19.1 Nm rated torque and operates at 400 V.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The 8LSA25.D8060S100-3 is a synchronous AC motor engineered by B & R Automation, with an input source requirement of 3x 400 to 3x 480 VAC, ±10% voltage tolerance. It is designed as a self-cooling unit and its mounting system is flange-based, though it can be fitted vertically or horizontally depending on the system.
The 8LSA25.D8060S100-3 motor features a top located connector with a 270-degree rotatable angular outlet. It delivers a rated torque of 0.52 Nm and a stall torque of 0.6 Nm. The motor’s peak torque reaches 2.4 Nm to enable high dynamic performance and its supported top speed reaches up to 9000 RPM. It consumes a rated power of 327 W and make use of an EnDat inductive encoder, designed for safety compliant feedback. The 8LSA motor possess a torque constant of 0.73 Nm/A and the voltage constant is measured as 43.98 V for every 1000 spins. It operates at a rated current of 0.71 A, with a peak current capacity of 3.7 A and its winding impedance is 34.63 Ohms at 20°C along with an inductive value of 49.6 mH, that contributes in smooth and controlled functionality. The 8LSA motor’s rotor inertia is 0.16 kg·cm² to provide fast response and it weighs about 1.3 kg, without a holding brake.
The 8LSA25.D8060S100-3 motor is IP65 protected, that makes it suitable for harsh and derated industrial environments. Its class F electrical insulation allows operations up to 428.15 K temperatures and its maximum installation elevation ranges up to 3300 ft. Further extension from these values derates the torque and current by 5%. The 8LSA motor’s integrated holding brake provides 2.20 Nm of static torque to maintain position during power loss or shutdown.
Frequently Asked Questions about 8LSA25.D8060S100-3:
Q: How does the EnDat inductive encoder improve the 8LSA25.D8060S100-3 motor’s performance?
A: The EnDat encoder provides highly accurate position feedback and ensures safe operation by detecting errors instantly. This results in smoother control and reliable motor positioning in critical applications.
Q: Why is the flange-based mounting system advantageous for the 8LSA25.D8060S100-3?
A: Flange mounting offers robust mechanical stability and easy integration into various equipment. It also allows flexible installation orientations, either vertical or horizontal, improving adaptability.
Q: What benefits does the ±10% voltage tolerance provide for the 8LSA25.D8060S100-3 motor?
A: Voltage tolerance ensures the motor maintains stable performance despite fluctuations in supply voltage. This enhances reliability and prevents damage under unstable grid conditions.
Q: How does the self-cooling design impact the 8LSA25.D8060S100-3 motor’s operation?
A: Self-cooling eliminates the need for external fans or cooling systems, reducing maintenance and noise. It also helps maintain optimal operating temperatures under continuous load.
Q: What role does the 34.63 Ohms winding impedance play in the 8LSA25.D8060S100-3 motor?
A: Higher winding impedance limits current spikes and smooths motor torque output. This characteristic contributes to quieter and more efficient motor operation.
