EL7201-9014 is an EL7xxx series ServoMotor Terminal manufactured by Beckhoff. This terminal weighs approx. 60 g, and features Compact Drive technology with an output current of 2.8 A and a load type that supports a permanent magnet-excited three-phase synchronous motor.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

✓ In-Stock!

EL7201-9014

  • Rated 4.6 (22 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • Stock: In-Stock, Ships 3-5 Days
  • Call for Expedited Shipping and Product Condition Options
EL7201-9014 is an EL7xxx series ServoMotor Terminal manufactured by Beckhoff. This terminal weighs approx. 60 g, and features Compact Drive technology with an output current of 2.8 A and a load type that supports a permanent magnet-excited three-phase synchronous motor.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Repairs
Sell Us Your Surplus
Have a EL7201-9014 to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

BECKHOFF EL7201-9014 is an EtherCAT Servomotor terminal. This model is designed to control the motion of proprietary and third-party, 3-phase synchronous motors. The EL7201-9014 is a 1-channel device and it comes with 1 x motor brake output connection, 1 x motor feedback input connection, 1 x STO input connection, and 2 x end position input connections. The connection between the terminal device and the motor can be established over an OCT cable. OCT (one cable technology) is a state-of-the-art cabling technology that eliminates the use of multiple cables for motor and encoder connections. However, only OCT supporting motors can be connected through OCT cables.

The EL7201-9014 is designed to supply up to 2.8 amperes of current in typical operating conditions. Improvement in the current supply or load-bearing capability of this device is possible with the help of an additional fan module. by inducing cooling airflow across the unit, up to 4.5 amperes of current can be drawn. The integrated PWM clock of this servomotor controller has a frequency of 16 Hz and its current controller frequency is 32 kHz. The BECKHOFF EL7201-9014 is known for its ultra-slim design as it is only 12 millimeters wide and weighs around 60 grams.

The outputs for motor brakes can supply a maximum voltage of 24 VDC and a maximum current of 0.5 A. with this model; you will be able to design your motion control applications with a variety of safety features as it offers quick and easy implementation of STO and SS1 through software. Moreover, the BECKHOFF EL7201-9014 ensures the safety and reliability of the system as it monitors numerous parameters for abnormalities. This product can be purchased from Wake Industrial with a one-year warranty period.

  • EL-7201-9014
  • el7201-9014
  • EL72O1-9O14

EL7201-9014 Technical Specifications

Load Type: permanent magnet-excited three-phase synchronous motor
Weight : 60g
Number of outputs: 3 motor phases, 2 motor holding brake
Supply volatge : 24V via the power contacts/ via E-bus
output current: 2.8A
Peak current: 5.7A
Rated power : 170W
PWM frequency: 16kHz
Load type : permanently excuted snchornous motors, inductive.
Velocity controller frequency: 16kHz

Frequently Asked Questions about EL7201-9014


Q: What type of industrial motor is the EL7201-9014 designed for?

A: This EL7201-9014 servo motor terminal is designed specifically for the AM81xx motor series. These motor series is one of Beckhoff's main product and the terminal helps to ensure high servo performance from the motor.

Q: What are the advantages of using EL7201-9014 with the AM81xx motor series?

A: The EL7201-9014 ensures the easy incorporation of the motor into the control solution. This simlifies commisioning and parameterization. The EL7201-9014 also makes the rate of servo drives to become even moe fily scalable.

Q: Is the EL7201-9014 supplied with the electrical cables it requires for wiring operations?

A: Electrical cables requried for the proper wiring of the EL7201-9014 have to be separately ordered. Only standardized cables manufactured by Beckhoff should be used with the device.

Q: What is the appropriate installation conditions for the EL7201-9014?

A: The installation of the EL7201-9014 should be handled by a professional who has gone through the documentation of the servo terminal. The terminal should be installed in a cool dry place and away from vibration.

Q: Does the EL7201-9014 require maintenance operations?

A: The EL7201-9014 is a maintenance free device. Operators should avoid opening up the housing of the terminal as this can cause permanent damage.
