BK1120

  • Rated 4.4 (38 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
    In-Stock, Ships 3-5 Days
  • Call for Expedited Shipping and Product Condition Options
BK1120 is an EK1xxx series EtherCAT coupler manufactured by Beckhoff. This coupler weighs approx. 150 g , and operates with 100 Mbaud data transfer rates and 24 V DC power supply.
Request a Quote Request Repair
✓ In-Stock!

Wake Industrial LLC is not an authorized distributor of this product.

BK1120

  • Rated 4.4 (38 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
    In-Stock, Ships 3-5 Days
  • Call for Expedited Shipping and Product Condition Options
BK1120 is an EK1xxx series EtherCAT coupler manufactured by Beckhoff. This coupler weighs approx. 150 g , and operates with 100 Mbaud data transfer rates and 24 V DC power supply.
Request a Quote Request Repair
Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
Surplus
Cash Icon Have a BK1120 to sell?
To Speak to a sales representative for pricing and lead time:
Phone
1-888-551-3082
International
1-919-443-0207
Email
sales@wakeindustrial.com
  • bk1120
  • BK112O

BK1120 Technical Specifications

Product type: EtherCat bus coupler
Protection rating : IP20
Interfaces: 2xRJ45
Connection length: 100 m
Bus terminals: 64
Data transfer rate: 100 Mbps
Power supply: 24 VDC
Input current: 70 mA
Electrical isolation: 500 V
Weight: 150 g

Frequently Asked Questions about BK1120


Q: What is the function of the bus coupler?

A: The coupler provides a connection between bus terminals and EtherCat protocol at fieldbus level.

Q: How many terminals can be connected?

A: By default, the coupler supports up to 64 stations. With the K-bus extension it can support up to 255.

Q: What is the function of the two RJ-45 interfaces?

A: The upper interface connects the coupler to the network. The lower interface provides an optional connection to other EtherCat devices.

Q: What are dimensions of the coupler?

A: Dimensions of the coupler are 51 x 100 x 69 mm.

Q: How can you install the coupler?

A: The coupler mounts on a 35 mm DIN rail.

Internal Product Review

  • ‘‘BK1120 is an EtherCat coupler with dual FastEthernet network interfaces.’’
