CX9020-0100 is a CX9020 series Embedded PC manufactured by Beckhoff. CX9020-0100 has neither a Windows operating system nor TwinCAT control software. This PC's dimensions (W x H x D) are 84 mm x 99 mm x 91 mm, it weighs 590 g, and it features an ARM Cortex-A8, 1 GHz processor and 1 GB DDR3 RAM storage.

CX9020-0100

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
CX9020-0100 is a CX9020 series Embedded PC manufactured by Beckhoff. CX9020-0100 has neither a Windows operating system nor TwinCAT control software. This PC's dimensions (W x H x D) are 84 mm x 99 mm x 91 mm, it weighs 590 g, and it features an ARM Cortex-A8, 1 GHz processor and 1 GB DDR3 RAM storage.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Exchange
Call to find out about our exchange credit for your defective unit.
Sell Us Your Surplus
Have a CX9020-0100 to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

Beckhoff Company manufactures the state-of-the-art CX series embedded PCs. These PCs are used in combination with I/O modules offering a space-saving controller, thanks to the DIN mounting rail capabilities. All CX series embedded PCs can be tailored to meet your budget, performance class, and complexity of the control task. While they can differ in terms of power supply and system interfaces, they can be plugged together into a modular control system design to meet the specific requirements of your task. The CX9020-0100 is an embedded PC that combines hardware PLC and Industrial PC technologies. It is ideal for tasks that require Industrial PC computing capacity and characteristics.

The CX9020-0100 can be configured to match the task at hand by adding or omitting interfaces and units. The DIN rail mounting significantly reduces installation space and cost. It is an Ethernet control system that comes with an ARM Cortex 1 GHz CPU. It can automatically detect the bus system (K/E-bus) and switch independently to match the corresponding module. The CX9020-0100 comprises memory features such as MicroSD flash memory, 1 GB DDR3 RAM main memory, and 128 KB NOVRAM persistent memory. Some of the interfaces include two switched Ethernet RJ45, four USB interfaces, an optional interface, and one DVI-D.

The CX9020-0100 does not come with an operating system and lacks a TwinCAT runtime environment. Some of the optional interfaces compatible with the CX9020-0100 include an audio interface, EtherCAT slave, PROFINET RT, controller, and Ethernet/IP slave. The permissible ambient operating temperature is -25 to 60 degrees Celsius which enables it to be used in climatically demanding situations. It has approvals and markings such as CE, GL, UL, and ATEX. The weight is approximately 590g and the maximum power consumption is 5W.

  • CX90200100
  • cx9020-0100
  • CX9O2O-O1OO

CX9020-0100 Technical Specifications

Control Software: -
Dimensions (W x H x D): 84 mm x 99 mm x 91 mm
Memory (RAM): 1 GB DDR3
Operating System: -
Processor: ARM Cortex-A8, 1 GHz
Weight: 590 g
