CX5130-0155

  • Rated 4.5 (35 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • Stock: Available
  • Call for Expedited Shipping and Product Condition Options
CX5130-0155 is a CX5130 series Embedded PC manufactured by Beckhoff. This PC's dimensions ( W x H x D) are 142 mm x 100 mm x 92 mm, it weighs 960 g, and it features an Intel Atom E3827, 1.75 GHz processor and 4 GB DDR3 RAM storage.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

✓ In-Stock!

CX5130-0155

  • Rated 4.5 (35 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • Stock: Available
  • Call for Expedited Shipping and Product Condition Options
CX5130-0155 is a CX5130 series Embedded PC manufactured by Beckhoff. This PC's dimensions ( W x H x D) are 142 mm x 100 mm x 92 mm, it weighs 960 g, and it features an Intel Atom E3827, 1.75 GHz processor and 4 GB DDR3 RAM storage.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Repairs
Sell Us Your Surplus
Have a CX5130-0155 to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The CX5130-0155 is an embedded PC in the CX series which is produced by Beckhoff Company. It can be tailored to meet specific requirements such as performance class, budget, and complexity of the task at hand. The embedded PC is a combination of Industrial PC and hardware PLC making it ideal for all control tasks on the factory floor. The modular design allows the user to omit or add interfaces to match any task which saves installation cost and space. Since it uses less power, it reduces the cost of production.

The CX5130-0155 comes with an Intel Atom® E3827 dual-core processor with a clock rate of 1.75GHZ which allows genuine multi-core technology. The interfaces in this Beckhoff embedded PC include Ethernet, USB, and DIV connections which are identical to those in the CX5000 series. An optional interface for further connections is provided. With this interface, further connection options are available, such as audio, CANopen, and PROFIBUS, among others. It features a TwinCAT 3 runtime (XAR) environment which enables the implementation of either PLC or PLC/motion control tasks. This environment allows the execution of motion control applications with interpolating axis movement. The operating system that runs the CX5130-0155 is Windows 10 IoT Enterprise LTSB 64 bit.

The CX5130-0155 Beckhoff embedded PC measures 142mm x 100mm x 92mm (W x H x D) and weighs at least 2 lbs. It features a 40 TC3 performance class, IP 20 protection class, and comes with CE, UL, and IECEx approvals and markings. It is equipped with an integrated 1-second UPS persistent memory, 4GB DDR3 RAM main memory, and CFast and Micro SD flash memory capabilities (cards not included). For diagnostic purposes, it features power, flash access, TC status, and bus status diagnostic LEDs.

  • CX51300155
  • cx5130-0155
  • CX513O-O155

CX5130-0155 Technical Specifications

Dimensions: 142 mm x 100 mm x 92 mm
Persistent Memory: Integrated 1-Second UPS (1 MB on Cfast Card)
Design : Compact Fanless Design.
Processor: Intel Atom® E3827
Number of Cores : 2
Control Software: TwinCAT 3 runtime (XAR)
Power supply: 24V DC
Protection Class: IP20
Maximum Power consumption: 14W
Maximum Power consumption (With laoding UPS): 20W

Frequently Asked Questions about CX5130-0155


Q: What additional accessories are requied by the CX5130-0155 for optimum operation?

A: Additional accessories required by the CX5130-0155 include MicroSD Cards, CFast cards, CR2032 battery, and the DVI-to-VGA passive adaptor. To prevent industrial accidents and sudden machine faliure, only accessories manufactued by Bechoff should be used with the processor.

Q: What are the X100, X101, X102, X103 USB interfaces on the CX5130-0155 designed for?

A: The four USB interfaces on CX5130-0155 are designed for connecting keyboards, mice, touchscreens, and other input and datastorage devices. The maximum power consumption permitted through each interface is 500mA

Q: What are the factors that affect the display resolution of monitors or control panel connected to the CX5130-0155?

A: Generally, the resolution on control panels and monitors depend on the cable quality, and cable length. The maximum distance is 5 meters, however longer distances can be achieved on panels containing the DVI extensions provided by Beckhoff.

Q: What are the optional interfaces on CX5130-0155 used for?

A: The optional interfaces are designed to extend the functionality of the CX5130-0155 beyond the basic equipment. These interfaces include the DVI-D, the Display Port(N011), and the audio interface (N020).

Q: What is the appropriate installation position for the CX5130-0155?

A: The CX5130-0155 should the installed in a horizontal position at an ambient temperature that does not exceed 600C.

Internal Product Review

  • ‘‘The CX5130-0155 easy to configure, easy to use and very durable. Absolute bargain!’’
